FTGMDC FT-8800 - SUMMARY AND INTRODUCTION; System Overview and Data

iv 1
D
NEW MESSAGE EDIT AND SENDING ...............................................................................8
D
CHECK SENT MESSAGE .....................................................................................................8
D
RECEIVING MESSAGE ........................................................................................................8
D
ALERT MESSAGE .................................................................................................................9
D
LONG RANGE MESSAGE ....................................................................................................9
D
CHECK MESSAGE STATUS ..................................................................................................9
■
VESSEL CHECK ................................................................................................................9
■
CHANNEL MANAGEMENT ...........................................................................................10
D
CHECK PRESENT CHANNEL ............................................................................................10
D
WORKING AREA SETUP (TOTAL 8 WORKING AREA) .....................................................10
■
NAVIGATION DATA SETUP ..........................................................................................10
D
NAVIGATION STATUS CHECKING LIST ...........................................................................11
D
SHIP’S TYPE CHECKING LIST ............................................................................................ 11
■
OWN SHIP DATA SETUP ..............................................................................................13
■
SYSTEM SETUP..............................................................................................................13
■
DIAGNOSTIC .................................................................................................................14
D
SELF TEST ..........................................................................................................................14
D
PASSWORD SETUP ...........................................................................................................14
D
ON/OFF RECORDING LIST ...............................................................................................14
D
TX/RX SELF TEST ...............................................................................................................14
7. ANTENNA INSTALLATION ........................................................................................... 15
■
VHF ANTENNA ..............................................................................................................15
■
GPS ANTENNA .............................................................................................................. 15
8. MAIN SET CONNECTION AND MAINTENANCE ..........................................................16
■
INSTALLATION DIAGRAM ............................................................................................16
■
CLEANING ....................................................................................................................16
■
FUSE REPLACEMENT .................................................................................................... 16
■
DIAMENSION ................................................................................................................ 17
■
Q & A .............................................................................................................................18
9. CHANNEL TABLE LIST ..................................................................................................19
1. SUMMARY
■
INTRODUCTION
FT-8800 is a AIS (Automatic Identication System) ship’s terminal operation system pro-
vide voyage data and message from ship to ship or ship to shore. Its compliant with
A.694(17), IEC62287-1 2006-03 standard requirement and fully matched GMDSS & IMO
rules.
FT-8800 consist of transceiver unit,control unit,display unit, VHF & GPS antenna. Trans-
ceiver unit including VHF Tx×1, TDMA Rx ×2, channel1 to DSC×1, interface port and built
in GPS Rx.
■
RELATED DATA
y
Static data
Call sign and ship’s name
MMSI
IMO
Length and beam
Ship’s type
GPS antenna position
y
Dynamic data
Ship’s position
UTC
COG
SOG
Heading
Navigation status
Rate of turn
y
Navigation data
Draught
Dangerous Cargo(Type)
Destination and ETA
y
Safety short message
