FTGMDC FT-8800 - CORE OPERATION TASKS; Message Management; Vessel Information Checks

8 9
NOTE: Total 16 messages for saving
D
ALERT MESSAGE
1. Press [MENU] to enter main operation
2. Press [CFM] to enter message edit
3. Press [
Y
][
Z
] for selection alert message and
then press [CFM] to enter
4. Press [
Y
][
Z
] select message
5. Press [CFM] to confirm alert message and
then the alert is deleted.
D
LONG RANGE MESSAGE
1. Press [MENU] to enter main operation
2. Press [CFM] to enter message edit
3. Press [
Y
][
Z
] for selection long range message
and then press [CFM] to enter
4. Press [
Y
][
Z
] select message
5. Press [CFM] to confirm long range message
and then the message is deleted.
D
CHECK MESSAGE STATUS
1. Press [MENU] to enter main operation
2. Press [CFM] to enter message edit
3. Press [
Y
][
Z
] for selection message status and
then press [CFM] to enter
■
VESSEL CHECK
1. Press [MENU] to enter main operation
2. Press [
Y
][
Z
] select vessel check then press
[CFM] to enter
3. Press [
Y
][
Z
] for selection, press [
A
][
B
] to
modify
4. After modification press [CFM] to request
checking
6. MAIN OPERATION
■
MESSAGE FUNCTION
NOTE: Please follow by main set instruction
D
NEW MESSAGE EDIT AND SENDING
1. Press [MENU] to enter main operation
2. Press [CFM] to enter message edit
3. Press [CFM] to edit new message
4. Press [
Y
][
Z
] for selection edit, press [
A
][
B
] to
modify
5. Press [CLR] to enter edit message status
6. Use keypad to edit message
7. Press [CFM] to save
8. Press [CFM] again to send message
D
CHECK SENT MESSAGE
1. Press [MENU] to enter main operation
2. Press [CFM] to enter message edit
3. Press [
Y
][
Z
] for selection sent message then
press [CFM] to enter
4. Press [
Y
][
Z
] select target message
5. Press [CFM] check message
NOTE: Total 8 messages for saving
D
RECEIVING MESSAGE
1. Press [MENU] to enter main operation
2. Press [CFM] to enter message edit
3. Press [
Y
][
Z
] for selection receiving message
and then press [CFM] to enter
4. Press [
Y
][
Z
] for selection target message
5. Press [CFM] check message details
11:45 ¼º¾»² ´
Ã
1. TASK CH: CH1:2087 CH2:2088
2. SYNC STATUS: Base Station
3. POS INFO: INT
4. COG INFO: INT
5. SOG INFO: INT
6. HDG INFO: invalid
7. ROT INFO: invalid
[ STATUS MESSAGE ]
SOG:0.0kt
POS:24°41.186N 118°41.490E ROT:____°Î
COG:202° HDG: ___°SATE:6
CHINAõ
03:32 ¼½¾¿² ³
µ SAFETY ADDR MSG TO>415000003
Ã
Ä
[ NEW MESSAGE ]
DOP:9.9 SOG:4.0kt
POS:24°41.062N 118°41.502E ROT:____°Î
COG:180° HDG: ___°
PUSH:ÀOPTION ÁMODIFY ÂEDIT
03:45 ¼½¾¿² ³
TYPE:B]
NAME:JS
MSG1:NONE
MSG2:NONE
> MMSI:415000003
NAME:
MSG1:NONE
MMSI:000000000
Ã
[ STATION- 1 ]
TYPE:A]
[ STATION- 2 ]
[ INTERROGATION ]
DOP:9.1 SOG:1.2kt
POS:24°41.164N 118°41.497E ROT:____°Î
COG:180° HDG: ___°
PUSH:ÀOPTION ÁMODIFY ÆEXIT
03:33 ¼½¾¿² ³
Ã
ACK DATE TIME MMSI TYPE
[ TXD MESSAGE ]
FIX:2D SOG:3.3kt
POS:24°41.051N 118°41.502E ROT:____°Î
COG:180° HDG: ___°
PUSH:ÀOPTION ÅVIEW ÆEXIT
03:34 ¼½¾¿² ³
Ã
ACK LR-C ACK DATE TIME TO MMSI
[ LR-C MESSAGE ]
SATE:2 SOG:4.4kt
POS:24°41.054N 118°41.503E ROT:____°Î
COG:180° HDG: ___°
PUSH:ÀOPTION ÅACK ÆEXIT
03:33 ¼½¾¿² ³
Î __/__ 01:58 COME>965623812 CAST
Î __/__ 01:35 COME>415000099 CAST
Î __/__ 01:33 COME>415000099 CAST
Î 4/10 07:24 COME>415000099 CAST
Î 4/10 07:23 COME>415000099 CAST
Î 4/10 07:22 COME>415000099 CAST
Î 4/05 12:20 COME>216284302 CAST
Ã
Î 4/11 02:04 COME>415890008 CAST
VIEW DATE TIME MMSI TYPE
[ RXD MESSAGE ]
PUSH:ÀOPTION ÅVIEW ÆEXIT
SATE:4 SOG:2.3kt
POS:24°41.073N 118°41.502E ROT:____°Î
COG:180° HDG: ___°
03:33 ¼½¾¿² ³
Î 00:00:18 AIS:HDG lost/invalid
Î 00:00:18 AIS:EXT EPFS lost
Î 00:00:18 AIS:no sensor POS INFO
Î 00:00:48 AIS:no valid COG INFO
Î 00:00:48 AIS:no valid SOG INFO
Ã
ACK TIME DESCRIPTION
[ ALM MESSAGE ]
FIX:2D SOG:3.3kt
POS:24°41.054N 118°41.503E ROT:____°Î
COG:180° HDG: ___°
PUSH:ÀOPTION ÅACK ÆEXIT
