5. Labels
All connectors have proper labels to identify each one. It is labeled
by color and description name. The colors are related to its functions:
Green – The green labels are related to the RPM sensors (Crank
Trigger and Cam Sync);
Yellow – Input sensors such as TPS, Engine Temp, Air temp, Fuel
Pressure, Oil Pressure, Back Pressure or any other 0-5V sensor, CAN
port;
Blue – Exclusively to O2 sensors (NTK or Bosch);
White – FT500 Aux connector, Nano connector, Extra Outputs, Extra
Inputs, Signals outputs to stock ECU and coils connectors;
Purple – Peak and Hold and fuel injectors (Primary bank);
Black – FT500, Main connector, Battery (-), Power Ground;
Red – Battery (+), Main and Injectors relays/fuses, 12V switch;
6. Diagrams
6.1 FT500/FT500 Aux - Inputs/outputs
From To
Connector Pin Wire color Connector Pin Function
FT500 24 Blue #1 PH odd cyl 5 Primary #1 injector
FT500 23 Blue #2 PH even cyl 5 Primary #2 injector
FT500 13 Blue #3 PH odd cyl 4 Primary #3 injector
FT500 Aux 6 Blue #4 PH even cyl 4 Primary #4 injector
FT500 Aux 8 Blue #5 PH odd cyl 2 Primary #5 injector
FT500 2 Blue #6 PH even cyl 2 Primary #6 injector
FT500 4 Blue #7 PH odd cyl 1 Primary #7 injector
FT500 6 Blue #8 PH even cyl 1 Primary #8 injector
FT500 Aux 1 White #1 Auxiliary “E” accelerator / “A” EXTRA inputs GPI W#1
FT500 Aux 5 White #2 Auxiliary “B” EXTRA inputs GPI W#2
FT500 Aux 7 White #3 Auxiliary “B” accelerator / “C” EXTRA inputs GPI W#3
FT500 9 White #4 Main “C” oil Oil pressure input
FT500 7 White #5 Main “B” H2O Engine temperature input
FT500 5 White #6 Main “C” fuel / “F” EXTRA inputs Fuel pressure input
FT500 3 White #7 Main “B” IAT Air temperature input
FT500 Aux 12 White #8 Auxiliary “H” EXTRA inputs GPI W#8
FT500 Aux 10 White #9 Auxiliary “J” EXTRA inputs GPI W#9
FT500 Aux 3 White #10 Auxiliary “D” throttle body / “K” EXTRA inputs GPI W#10
FT500 11 White #11 Main “C” TPS / “F” throttle body TPS input
FT500 18 Gray #1 Main “G” coils odd / “F” coils even Coils #1 and #6
FT500 16 Gray #2 Main “C” coils odd / “G” coils even Coils #5 and #8
FT500 14 Gray #3 Main “B” coils odd / “C” coils even Coils #7 and #4
FT500 12 Gray #4 Main “F” coils odd / “B” coils even Coils #3 and #2
FT500 10 Gray #5 Main “A” EXTRA outputs GPO G#5
FT500 Aux 2 Gray #6 Auxiliary “B” EXTRA outputs GPO G#6
FT500 Aux 4 Gray #7 Auxiliary “C” EXTRA outputs GPO G#7
FT500 1 Gray #8 Main “D” EXTRA outputs GPO G#8
FT500 Aux 13 Yellow #1 Auxiliary “H” EXTRA outputs GPO Y#1
FT500 Aux 14 Yellow #2 Auxiliary “G” EXTRA outputs GPO Y#2
FT500 Aux 15 Yellow #3 Auxiliary “B” throttle body / “F” EXTRA outputs GPO Y#3
FT500 Aux 16 Yellow #4 Auxiliary “A” throttle body / “E” EXTRA outputs GPO Y#4
To Next Page
