Maintenance Section 5-3
MAINTENANCE
FB42 08/01
© 2004 Alamo Group Inc.
MAINTENANCE
GEARBOX
The gearbox should be full (18 ounces).54 liters and not require additional lubricant unless the box is cracked or
a seal is leaking. It is recommended that the 1/8" oil level plug (Figure 2) be removed after every 10 hours of
operation. If required, oil should be added until it runs out hole.
Recommended lubricant is NLGI 000 Grease, P/N 00765444.
NOTE: Make sure mower is level when checking oil in the gearbox.
NOTE: Overfilling of Gearbox will cause pressure to build up and cause Grease Seals to leak.
FIGURE 2. Gearbox Lubrication
FILL
CHECK
