(F codes continued)
Code Name Data setting range
Incre-
ment
Unit
Change
when
running
Data
copying
Defaul
t
setting
F10
Electronic Thermal
Overload
Protection for
Motor 1
(Motor
characteristics)
1: For a general-purpose motor with shaft-driven
cooling fan
2: For an inverter-driven motor with separately
powered cooling fan
Y Y 1
F11
(Overload detection
level)
0.00: Disable, 0.01 to 100.0
1 to 135% of the rated current (allowable continuous
drive current) of the motor
0.01 A Y
Y1
Y2
See
Table
A.
F12
(Thermal time
constant)
0.5 to 75.0
0.1 min Y Y 5.0
F14
Restart Mode after
Momentary Power
Failure
(Mode selection)
0: Disable restart (Trip immediately)
1: Disable restart (Trip after a recovery from power
failure)
2: Trip after decelerate-to-stop *2
4: Enable restart (Restart at the frequency at which the
power failure occurred, for general loads)
5: Enable restart (Restart at the starting frequency)
Y Y
1
F15
Frequency Limiter
(High
)
0.0 to 400.0
0.1 Hz Y Y 70.0
F16
(Low)
0.0 to 400.0
0.1 Hz Y Y 0.0
F18
Bias(Frequency
command 1)
-100.0 to 100.0 *1
0.01 % Y* Y 0.00
F20
DC Braking 1
(Braking startin
g
frequency)
0.0 to 60.0
0.1 Hz Y Y 0.0
F21
(Braking level)
0 to 100 *2
1 % Y Y 0
F22
(Braking time)
0.00 (Disable), 0.01 to 30.00
0.01 s Y Y 0.00
F23
Starting Frequency
0.1 to 60.0
0.1 Hz Y Y 1.0
F24
(Holding time)
0.00 to 10.00
0.01 s Y Y 0.00
F25
Stop Frequency
0.1 to 60.0
0.1 Hz Y Y 0.2
F26
Motor Sound
(Carrier frequency
)
0.75 to 16
1 kHz Y Y
2
F27
(Tone)
0: Level 0 (Inactive)
1: Level 1
Y Y 0
F30
Analog Output
[FMA]
(Voltage
adjustment)
0 to 300
1 % Y* Y 100
F31
(Function)
Select a function to be monitored from the followings.
0: Output frequency 1 (before slip compensation)
1: Output frequency 2 (after slip compensation)
2: Output current
3: Output voltage
7: PID feedback amount (PV)
9: DC link bus voltage
14: Calibration
15: PID command (SV)
16: PID output (MV)
Y Y 0
18
