-12-
Reference Guide - Main Unit
1.
Pull out Paper Tray 1 until it stops.
2.
Slightly lift the front side of Paper Tray 1 and remove
Paper Tray 1.
3.
Push in the Envelope Tray.
4.
On the Home screen, login to the Administrator Mode.
5.
Select [Device] > [System Settings] > [Other Settings] >
[Tray 1 Configuration], and then tap on [Coupled as
Envelope Feeder].
Ta n d e m Tra y s
The paper feeding method is the same for Paper Trays 3 (left side) and 4 (right side).
The top face of loaded paper is the surface printed on.
Loadable paper
Paper size JIS B5 , A4 , 8.5 x 11”
Paper weight Single side printing 52 to 300 g/m
2
Maximum number of
sheets
Tray 3 980 sheets (P paper)
Tray 4 1,280 sheets (P paper)
1
To Next Page
