16 Appendix
658
Appendix
16
Paper Margin
[Paper size] is set to [A Size] by factory default. If the print data is larger than the active
coordinates area, the machine prints the data on the next larger A series paper (for example,
the next larger size of A4 is A3).
When you set the paper margins, however, the active coordinates area is determined by
subtracting the area set in paper margins from the active coordinates area obtained in the
area determination mode. Therefore, set the paper margins if the data is printed on larger
paper than specified. Set the range from 0 to 99 mm. The default value is 0 mm.
HP-GL/2 Emulation Settings
The following table shows the emulation parameters and their values for HP-GL2 emulation.
HP-GL Settings List
Items that can be set using the HP-GL mode menu are explained in two groups: basic
settings and extended settings.
Basic Settings
Parameter Item No. Value
Document size 101 Sets the document size created by a computer.
[0] : A0
[1] : A1
[2] : A2
[3] : A3
[4] : A4
[5] : A5
[10] : B0
[11] : B1
[12] : B2
[13] : B3
[14] : B4
[15] : B5
[99] (Default) : Auto
[100] : Paper
When [Auto] is selected, the settings of the Scaling mode, the Area
Determination mode, and the Paper Margin settings of Print Control become
enabled.
Note • If the document size other than [Auto] is selected, the settings under [Auto
layout] become [ON].
• Depending on the combination of [Document size] and [Paper size], the
document is printed at a scale of 100%.
To Next Page
