Clearing Paper Jams
Paper Jam in Tray Side Cover (Cover C)
1: Open Side Cover located on the bottom of the machine (Door C).
2: Open the door wide enough to allow access to the tray feed area.
3: Gently remove jammed paper. Ensure there are no paper scraps and torn pieces left
inside. Close the Side Cover.
Paper Jam in Top Left Cover (Cover D)
CAUTION: When removing paper, ensure not to touch the Transfer Belt (the black film
belt) inside the Cover on the upper left side. Scratches, dirt or oil from touching the belt
reduces print quality. There may be some toner on the transfer roller. However this does
not affect image quality.
1: Power Off the machine.
(Door A will not open
without the machine being
turned Off.)
2: Raise the release lever
to open Cover A.
3: Raise the release lever
to open Cover D.
4: Gently remove jammed
paper. Close Cover D and
Cover A.
1
2 3
1
2
3
4
37
37
To Next Page
