Replacing Consumables
Replacing R2 & R3 Booklet Staple Cartridge (For C Finisher)
1: Ensure machine is idle before opening the A1 Finisher Door. Open the Finisher Door.
2: Pinch the two Booklet Maker access handles together, and pull out the Stapling Unit.
3: Squeeze the Staple Cartridge handles and pull to remove the used cartridge..
4: Unpack and install new cartridge. It will click into place when installed correctly.
5: Return the Stapling Unit to its original position. Close the Finisher Front Door.
Replacing Booklet Staple Cartridge (For B1 Finisher)
1: Make sure that the machine has stopped copying / printing, then open the top of the
Finisher, facing the scanner.
2: Squeeze the tabs on the side of the staple cartridge and the lift the cartridge to remove
it from the stapler.
3: Repeat the process to remove the second cartridge.
4: Squeeze the tabs on the cartridge and install it into the stapler.
5: Push down gently on the cartridge until the second cartridge.
6: Repeat steps 4 – 5 to install the second cartridge. Close the top of the Finisher.
1
2
3
4
5
1
2 3
For used cartridges disposal, please call us @ 1-300-88-1163 for collection.
