2 Paper and Other Media
52
Paper and Other Media
2
6 Insert the small protrusions at the bottom of the guide into the holes corresponding to
the paper size (1). Insert the protrusion on the tray into a hole corresponding to the
paper size on the top of the guide, and tighten up the screw (2).
7 Pull up the lever of the end guide (1). Move
the lever along the slot, and set it at the
position corresponding to the paper size (2).
And then press the lever down (3).
Important • Adjust the end guide correctly to the size
of the paper. If the end guide is not
adjusted correctly, the machine cannot
feed the paper properly, resulting in paper
jams.
Note • The slot to the left of 8.5" is not used.
8 Open the end guide (1), and load and align
the edge of the paper against the right edge
of the tray with the side to be copied or
printed on facing down (2).
Important • Do not load paper above the maximum fill
line ("MAX" in the right figure). It may
cause paper jams or machine
malfunction.
9 Close the end guide securely.
10 Push the tray in gently until it stops.
