ESC/P-K Emulation
587
Appendix
15
Form overlay 64 Constantly performs Form Overlay by selecting a form name (No. 01-64)
registered on the machine.
[0] (Default) : Off
[1-64] : No. 1 - No. 64
Important•Since the default value is selected for this feature, this setting is not
affected when an extended commend is received.
•Once a form name is selected, it continues to be displayed even if the
form is deleted. When a form name is selected using the up and
down arrow keys, it is not displayed. In this case, the setting is set to
"Off".
Stapling 66 Sets the stapling position.
[0] (Default) : Off
[1] : Top left
[2] : Top Double
[3] : Top Right
[4] : Left Double
[5] : Right Double
[6] : Bottom Left
[7] : Bottom Double
[8] : Bottom Right
Bypass Tray -
Wait User
67 Sets whether to suspend the print processing when feeding paper from
the Bypass Tray. Processing is resumed by a user operation on the
machine.
[0] : Off
[1] (Default) : On
Form Type 68 Sets the form type.
[0] (Default) : ESC/P-K
Punching 69 Select the position for punching holes.
[0] (Default) : Off
[1] : Top
[2] : Bottom
[3] : Left
[4] : Right
Number of holes 70 Select the number of punch holes.
[0] (Default) : 2 holes
[1] : 3 holes
[2] : 4 holes
Binary character
strings
72 Sets the character strings to be specified when entering commands in
hexadecimal format.
[0] (Default) : Off
[1] : &$%$
[2] : $?!#
0 Style 73 Sets the typeface for "0".
[0] (Default) : 0
[1] :
Number of sets 74 Sets the method of specifying the number of print sets.
[0] : Protocol
[1] : Panel
[2] (Default) : Command
Setting Item
Item
Number
Value
