If it is a Paper Size
Set the document size from the obtained active coordinates area and the origin point
setting. The document size can be selected from six sizes of A series paper (A0, A1,
A2, A3, A4, or A5).
How to Determine Document Size
The document size is determined by comparing with the hard clip area of each paper
size based on the active coordinates area obtained in the scaling mode, paper margin,
and area determination mode.
If the Scaling Mode is a Paper Size
1) Obtain the coordinate area to be active from the HP-GL data entered, in
accordance with the area determination mode.
2) As a margin, add the larger value of either the font size specified in the page, the
default size or one half the specified pen width, to the active coordinates area
obtained in step 1.
3) Subtract the value set in paper margins from the active coordinates area obtained
in step 2.
4) The minimum size that includes the active coordinates area obtained in step 3 will
be the document size.
If the Scaling Mode is the ACA
1) Obtain the coordinate area to be active from the HP-GL data entered, in accord
with the area determination mode.
2) As a margin, add the larger value of either the font size specified in the page, the
default size or one half the specified pen width, to the active coordinates area
obtained in step 1.
3) Subtract the value set in paper margins from the active coordinates area obtained
in step 2.
4) The ACA obtained in the process up to step 3 will be the document size.
For Example:
If the following data is entered when the scaling mode is paper size, origin position is
Auto, paper margin is 10mm, and area determination mode is IP:
All pen width settings are 0.1 mm.
The following data does not contain a character size specification command and the
A3 physical size of the area specified by IP/IW.
IN;
IP-8399,-5938, 8399, 5938;
IW-8399,-5938, 8399, 5938;
PU;
SP1;
:
:
SP0;
1) As the area determination mode is IP, the active coordinates area is specified as
the area -8399,-5938,8399,5938 by an IP command.
