186 A Appendix
The following describes how to install additional memory to the printer.
The printer has one slot for installing a memory card. If you want to add memory when the
slot already has a memory card, replace the memory card with the one with larger capacity.
Important
• Before plugging or unplugging the interface cable connector, be sure to switch off the printer or unplug
the power cord from the power outlet. Plugging or unplugging the connector when the printer is on can
cause printer failure.
1. Switch the power off by pressing the power
switch on the left side of the printer to the
<O> position.
Unplug the power cord from the power
outlet and the printer.
2. Loosen the screw on the rear cover of the
printer, and open the cover.
3. Remove the rear cover from the printer by
pulling out the bottom tab of the cover from
the slot, tilting the cover, and pulling out the
top tab of the cover from the slot.
4. If a network expansion card is installed,
remove it temporarily.
5. If another memory card is already installed,
push the retaining clips on both ends in the
outward direction. After the memory card
pops up, pull it out at an angle.
To Next Page
