10. Use the numbered markers next to the drum roller to find the mark on the drum. For example, a dot in column
2 on the check sheet means that there is a mark in drum region “2”.
11. Turn the edge of the drum cartridge toward you while looking at the drum surface to find the mark.
• To avoid print quality problems, DO NOT touch the surface of the drum cartridge, only the edge.
• You can turn the drum cartridge gear more easily by pulling down the black levers. When you have
finished turning the gear, push the levers back to the original position.
258
