Board Installation
LCD Header (LCD)







Signal Pin Pin Signal
n.c.
1 2
GND
n.c.
3 4
GND
Key
5 6
RFU
LAN Action
7 8
LAN Link
HD aktiv
9 10
Alert
Message
11 12
Sleep
Power
13 14
VDD
Front USB (FRNT USB - black)






Signal Pin Pin Signal
Key 1 2 n.c.
Power
3 4
Power
USB4-
5 6
USB5-
USB4+
7 8
USB5+
GND
9 10
GND
Key 11 12 n. c.
HDA compliant Front Panel Audio Header (AUDIO - yellow)





Signal Pin Pin Signal
PORT1-L
1 2
Analog GND
PORT1-R 3 4 Presence Detect
PORT2-R 5 6 PORT1 Sens Return
Jack Sens Send 7 8
Key
PORT2-L 9 10 PORT2 Sens Return
IEEE 1394 Header (FRNT1394 – grey)





Signal Pin Pin Signal
TPA+
1 2
TPA-
GND 3 4 GND
TPB+ 5 6 TPB-
P12VP 7 8 P12VP
Key 9 10 GND
A26361-D2568-Z120-1-7619, edition 1 13
