Fujitsu AB12

OUTDOORUNITINTERNALLAYOUT
FAN2 FAN1
(FRONT)
OILSEPARATER1（FORCOMP1,2） RECEIVERTANK

ACCUM OILSEPARATER3
(CENTRAL)
OILSEPARATER2 
(FOR COMP3）
COMP2
COMP3
COMP1
CONTROL
BOX
(FRONT)
OUTDOORUNITCONTROLBOX
INTERNALLAYOUT
POWERRELAY3CAPACITOR1
OUTDOORP.C.B
POWER
RELAY2
COMMUNICATION
POWERRELAY1
P.C.B
CAPACITOR2
MAGNETIC
RELAY1
MAGNETIC MAGNETIC POWER TRANSMISSION
RELAY3 RELAY2
TERMINAL
TERMINAL
