Ref Parts No. Ord Ref Parts No. Ord
No. AOY90TPAMF Q'ty No. AOY90TPAMF Q'ty
Description Description
354 PRESSURE SWITCH ( HIGH ) 9355094009 WIRE ASSY ( HEATER ) 9363255003
354-1 PRESSURE SWITCH ( LOW ) 9703269004 253-1 WIRE ASSY 9702313036
39 PROPELLER FAN 9361726000 816 WIRE CLAMP METAL 313584219902
9 REAR PANEL.PAINTED 9361712027 253 WIRE WITH CONNECTOR 9703878015
453 RECEIVER TANK ASSY 9366371007 253 WIRE WITH CONNECTOR 9703879012
226 REINFORCEMENT 9361697003 XTAL.RESONATOR 9703542015
289 REINFORCEMENT 9361704008 326 3-WAY JOINT 9354901001
846 RELAY 9304375005 344 4-WAY VALVE 313943302804
RELAY 9701566013 344-1 4-WAY VALVE 313947302811
RESISTOR.CHIP 0200306667 344-2 4-WAY VALVE 9353532008
RESISTOR.CHIP 0201010662 344-3 4-WAY VALVE 9703884009
RESISTOR.CHIP 0200230269
RESISTOR.CHIP 0200230740
RESISTOR.CHIP 0200231013
RESISTOR.CHIP 0201010013
RESISTOR.CHIP 0201010747
RESISTOR.CHIP 0201010907
RESISTOR.CHIP 0201011010
RESISTOR.METAL OXIDE 0201107997
RESISTOR.WIRING 0200244372
185 RUBBER BUSHING 313005066051
107 RUBBER SEAT-A 9364084008
128-1 RUBBER ( DISCHA.PIPE ) 313155086308
47-2 RUBBER ( DISCHA.PIPE ) 313185159802
47-1 RUBBER ( DISCHA.PIPE ) 313194159807
SCREW 0700008023
949-2 SCREW.PAINTED 9302348001
949-1 SCREW.PAINTED 9305648009
SEMICON ACCESSORY 0000393010
915-1 SENSER(PRESSURE) 9703890000
166 SEPARATE WALL-L 9361695009
167 SEPARATE WALL-R 9361696006
164 SEPARATE WALL-UPPER 9361693005
762 SIDE PANEL-L.PAINTED 9361705029
761 SIDE PANEL-R.PAINTED 9361706026
599 SIGNAL PCB ASSY 9703728013
108 SLEEVE-A 9364085005
SOCKET.PWB 0500296033
343-1 SOLENOID 9703888014
343-2 SOLENOID 9703888021
343-3 SOLENOID 9703888038
343-4 SOLENOID 9703888045
343-5 SOLENOID 9703888052
457 SOLENOID 9703889011
457-1 SOLENOID 9703889028
343-2 SOLENOID 9703342059
343-3 SOLENOID 9703342066
343-4 SOLENOID 9703342073
343-5 SOLENOID 9703342080
343-9 SOLENOID 9703342097
343-6 SOLENOIDE 9703888069
343-7 SOLENOIDE 9703888076
343-8 SOLENOIDE 9703888083
408/55 SPECIAL NUT M8 313252257701
117-3 SPECIAL WASHER M6 313306391007
737 SUC PIPE K ASSY 9363934007
595 SUC PIPE N ASSY 9363929003
621 SUC PIPE S ASSY 9365071007
621-1 SUC PIPE T ASSY 9365514009
596 SUC PIPE Y ASSY 9365436004
331 SUC PIPE A ASSY 9363903003
331-2 SUC PIPE D ASSY 9365513002
SWITCH.PUSH 9700450016
SWITCH.ROTARY 9701694013
SWITCH.SLIDE 9701393015
109 TERMINAL COVER 9364087009
109-1 TERMINAL COVER 9366265009
111 TERMINAL PACKING 9364086002
11-1 TERMINAL PACKING 9366264002
815-2 TERMINAL 3P 9363276046
815-1 TERMINAL 5P 9363275018
652-1 THERM.HOLDER PIPE 313714262805
454 THERMISTOR ASSY 9703880018
454-1 THERMISTOR ASSY 9703881015
163-21/184-1 THERMO.SPRING-A 313728262708
343-2 TRANS SW 9703586019
TRANSISTOR 0000164016
TRANSISTOR 0000780094
TRANSISTOR 0000781053
TRANSISTOR 0000936033
85 VALVE PLATE 9363063004
VARISTOR 0000038010
VARISTOR ( ARRESTER ) 0600280154
– 174 –
Models : AOY90TPAMF
