Fujitsu ABY24FBBJ User Manual

PARTS LIST
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
ABY24UBBJABY14UBBJ ABY18FBBJ ABY18UBBJ ABY24FBBJ
Ref.
No.
Description
Ord.
Q'ty
Part No.
ABY14FBBJ
2004.04.02 31
69 Louver 9358561010 9358561010 9358561010 9358561010 9358561010 9358561010
8-1 Air Filter 9358567029 9358567029 9358567029 9358567029 9358567029 9358567029
34 Capacitor (Fan Motor) 2.3µF/450V -- --- -- -- -- -- --- -- 9703306044 9703306044 9703306044 9703306044
34 Capacitor (Fan Motor) 1.6µF/400V 9704305039 9704305039 -- -- --- -- -- -- --- -- -- -- -- --- -- -- -- ---
36-2 Cord Holder Metal 9356362008 9356362008 9356362008 9356362008 9356362008 9356362008
56 Sirocco Fan Assy 9385258006 9385258006 9385258006 9385258006 9385258006 9385258006
67 Rubber (Vibration-proof) 9385102002 9385102002 9385102002 9385102002 9385102002 9385102002
68 Cap, Plastic 9358563007 9358563007 9358563007 9358563007 9358563007 9358563007
108 Base Assy 9359061038 9359061038 9359061038 9359061038 9359061038 9359061038
109 Casing, Plastic 9358543009 9358543009 9358543009 9358543009 9358543009 9358543009
124 Dew Proof Plate 9359196006 9359196006 9359196006 9359196006 9359196006 9359196006
126 Motor Fixing Table Assy 9358591000 9358591000 9358591000 9358591000 9358591000 9358591000
127 Drain Hose Assy 9359242000 9359242000 9359242000 9359242000 9359242000 9359242000
138 Separate Wall-A 9358584002
9362513029
9358584002 9358584002 9358584002 9358584002 9358584002
146 Evaporator Assy KB07 -- -- --- -- -- -- --- -- -- -- -- ---
-- -- --- --
93625130369362513036 9362513036
146 Evaporator Assy KB45 93625130299362513029 -- -- --- -- -- -- --- --
160 Drain Pan Assy 9358568002 9358568002 9358568002 9358568002 9358568002 9358568002
164 Fan Motor Assy-IN MFA-24JTT --- -- -- -- -- --- -- -- -- --- -- -- -- -- --- -- 9601527015 9601527015
164 Fan Motor Assy-IN MFA-18JTT --- -- -- -- -- --- -- -- 9601527022 9601527022 -- -- --- -- -- -- --- --
164 Fan Motor Assy-IN MFA-14JTT 9601527039 9601527039 - -- --- -- - --- --- -- - --- -- --- - --- -- --- -
173 Hanger Bracket-L 9358596005 9358596005 9358596005 9358596005 9358596005 9358596005
174 Hanger Bracket-R 9358595008 9358595008 9358595008 9358595008 9358595008 9358595008
184-1 Thermistor Spring-A 313728262708 313728262708 313728262708 313728262708 313728262708 313728262708
187 Clamp No. 1219 313361271706 313361271706 313361271706 313361271706 313361271706 313361271706
187-1 Clip (Cable) 9352715006 9352715006 9352715006 9352715006 9352715006 9352715006
195 Clamp SKB-100 313361275805 313361275805 313361275805 313361275805 313361275805 313361275805
196-1 Clamp SKB-3M 312300787605 312300787605 312300787605 312300787605 312300787605 312300787605
210 Main Relay 9353611017 9353611017 9353611017
211 Cushion Rubber 313806328306 313806328306 313806328306
223 Control Box 9358600016 9358600016 9358600016 9358600016 9358600016 9358600016
-- -- --- --
-- -- --- --
-- -- --- --
-- -- --- --
-- -- --- --
-- -- --- --
234 Thermistor Assy-Room 9703299087 9703299087 9703299087 9703299087 9703299087 9703299087
235 Thermistor Assy-Pipe 9900022020 9900022020 9900022020 9900022020 9900022020 9900022020
9704557094
(EZ-001LWSE-C)
9704557551
(EZ-00100HSE-C)
9704557216
(EZ-002YWSE-C)
9704557551
(EZ-0021HSE-C)
9704557131
(EZ-002TWSE-C)
9704557148
(EZ-00210HSE-C)
236 Controller PCB Assy
240 Remote Control Unit AR-JW1 - -- --- -- - 9371190013 - --- -- -- - 9371190013 - --- -- --- 9371190013
240 Remote Control Unit AR-JW2 9371190020 -- -- --- -- 9371190020 - --- -- --- 9371190020 - -- --- -- -
320 Flap (Upper)-F 9358538012 9358538012 9358538012 9358538012 9358538012 9358538012
321 Flap (Lower) 9358541012 9358541012 9358541012 9358541012 9358541012 9358541012
338 Motor Fixture 9358594001 9358594001 9358594001 9358594001 9358594001 9358594001
361 Bushing 9357942001 9357942001 9357942001 9357942001 9357942001 9357942001
361-2 Bushing-B, Plastic 9358554005 9358554005 9358554005 9358554005 9358554005 9358554005
361-3 Bushing-C, Plastic 9358553008 9358553008 9358553008 9358553008 9358553008 9358553008
365-1 Special Screw 9359092001 9359092001 9359092001 9359092001 9359092001 9359092001
365-2 Special Screw 9359091004 9359091004 9359091004 9359091004 9359091004 9359091004
381 Locking Spacer, KGLS-4S 313209391506 313209391506 313209391506 313209391506 313209391506 313209391506
385 Indicator PCB Assy EZ-0964HSE-D 9701873012 9701873012 9701873012 9701873012 9701873012 9701873012
407 Motor Rod 9358560006 9358560006 9358560006 9358560006 9358560006 9358560006
408 Louver Link 9358556009 9358556009 9358556009 9358556009 9358556009 9358556009
416 Insulation (Panel)-A 9358574003 9358574003 9358574003 9358574003 9358574003 9358574003
417 Insulation (Panel)-B 9358914007 9358914007 9358914007 9358914007 9358914007
9358914007
418 Insulation (Flap Base) 9358572009 9358572009 9358572009 9358572009 9358572009
9358572009
