OUTDOOR UNIT
AOY 14US DJ L
2 Fan Cover 9304109006 9304109006
4 Emblem-Rear 9351355005 9351355005
5 Cabinet, Painted
9302936017 9302936017
7 Connector Cover (Cabinet) 9357970004 9357970004
9 Cabinet Rear Panel 9303744017 9303744017
12 Base Assy, Painted 9310889077 9310889077
13 3-Way Valve 9372205105 9372205105
14 2-Way Valve 9372204030 9372204030
16 Condenser
Assy
9373131045 9373131014
18 Suction Pipe 9364832005 9364827001
20 Discharge Pipe Assy 9364830001 - --- -- ---
32-2 Control Box Metal-A 9355843003 9355843003
34 Capacitor (Fan Motor) 9704305039 9704305039
37 Running Capacitor 9704436115 9704436115
38 Capacitor Clamp Metal 313468061808 313468061808
39 Propeller Fan Assy 9351589011 9351589011
42 Bracket (Motor) 313166243804 313166243804
51 Special Nut M5 (For Comp.) 9359430018 9359430018
55 Special Nut M8 (For Comp.) 9355091008 9355091008
R ef.
No.
Des cription
Ord.
Q'ty
P art No.
AOY 14F S DJ
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
98 Fan Ring 313166296109 313166296109
105 Compressor Assy 9364723006 9364723006
107 Rubber Seat-A (For Comp.) 9359425014 9359425014
109 Terminal Cover (For Comp.) 9364724003 9364724003
138 Separate Wall Assy 9303729014 9303729014
164 Fan Motor Assy-Out 9601113010 9601113010
259 Muffler -- -- --- -- 313505083900
272 Strainer 9357309002 9301340006
329 Coupling Pipe Assy not availablenot available
344 4-Way Valve -- -- --- --
373 Grip 313166178700 313166178700
9970036019
412 Terminal Gasket (For Comp.) 9351921019 9351921019
420 Capillary Assy 93721971109372197189
423 Noise Insulation-F 9350944019 9350944019
527 Protection
Net
9355444002 9355444002
734 Cabinet Top Plate 9302937014 9302937014
745 Motor Support 313166036308 313166036308
982-1 Cord Clamp 9356857009 9356857009
982-2 Cord Clamp-B 9356858006 9356858006
2004.03.30 33
To Next Page
