Fujitsu ABYG36LRTE User Manual

¢
Cooling capacity (Triple)

Cassette type
Model: AUYG30LRLE × 3
AFR
m
3
/h
4,800
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 17.51 2.75 22.49 17.62 2.79 23.25 19.15 2.81 24.78 19.22 2.84 25.55 20.75 2.85 27.08 20.66 2.89 28.62 22.02 2.91
-10 19.98 17.33 2.76 22.27 17.44 2.80 23.02 18.97 2.81 24.55 19.02 2.84 25.30 20.54 2.86 26.82 20.46 2.89 28.34 21.79 2.91
0 19.80 17.17 2.94 22.05 17.28 2.98 22.80 18.78 3.00 24.30 18.84 3.03 25.05 20.34 3.05 26.57 20.26 3.07 28.07 21.58 3.10
5 19.75 17.13 3.06 22.01 17.23 3.11 22.75 18.73 3.13 24.25 18.79 3.16 25.01 20.29 3.18 26.51 20.21 3.21 28.01 21.53 3.24
10 19.55 17.10 3.45 21.78 17.21 3.50 22.51 18.70 3.52 24.00 18.77 3.55 24.74 20.26 3.57 26.23 20.19 3.61 27.71 21.50 3.65
15 18.99 16.90 3.56 21.14 17.18 3.62 21.87 18.67 3.64 23.30 18.73 3.67 24.02 20.23 3.70 25.47 20.15 3.73 26.90 21.46 3.77
20 19.24 17.06 3.97 21.42 17.35 4.03 22.17 18.86 4.04 23.62 18.91 4.09 24.35 20.44 4.11 25.81 20.35 4.15 27.28 21.67 4.19
25 19.42 17.07 4.71 21.64 17.36 4.78 22.39 18.87 4.80 23.86 18.93 4.85 24.60 20.45 4.87 26.07 20.37 4.92 27.55 21.70 4.97
30 19.05 16.22 5.37 21.22 16.49 5.45 21.95 17.94 5.47 23.38 17.99 5.54 24.11 19.43 5.56 25.55 19.35 5.61 27.00 20.63 5.67
35 17.38 15.85 5.99 19.35 16.21 6.08 20.02 17.63 6.11 21.35 17.68 6.18 22.00 19.10 6.20 23.32 19.02 6.27 24.65 20.26 6.33
40 17.21 14.97 5.67 19.17 15.40 5.75 19.82 16.75 5.79 21.13 16.80 5.84 21.78 18.15 5.87 23.09 18.08 5.93 24.39 19.25 5.99
46 13.70 13.57 5.53 15.27 14.57 5.60 15.78 15.44 5.63 16.81 15.90 5.69 17.35 17.17 5.72 18.39 17.09 5.78 19.42 18.19 5.83

Duct type
Model: ARYG30LMLE × 3
AFR
m
3
/h
5,700
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 15.78 3.03 22.49 15.88 3.08 23.25 17.26 3.10 24.78 17.32 3.13 25.55 18.69 3.14 27.08 18.62 3.18 28.62 19.84 3.21
-10 19.98 15.62 3.04 22.27 15.72 3.09 23.02 17.09 3.10 24.55 17.14 3.13 25.30 18.51 3.15 26.82 18.44 3.18 28.34 19.64 3.21
0 19.80 15.47 3.24 22.05 15.57 3.28 22.80 16.92 3.30 24.30 16.98 3.34 25.05 18.33 3.36 26.57 18.25 3.39 28.07 19.45 3.42
5 19.75 15.44 3.38 22.01 15.52 3.43 22.75 16.88 3.45 24.25 16.93 3.49 25.01 18.29 3.51 26.51 18.21 3.54 28.01 19.40 3.57
10 19.55 15.41 3.80 21.78 15.50 3.86 22.51 16.85 3.88 24.00 16.91 3.92 24.74 18.26 3.94 26.23 18.20 3.98 27.71 19.37 4.02
15 18.99 15.23 3.93 21.14 15.48 3.99 21.87 16.83 4.01 23.30 16.88 4.05 24.02 18.23 4.07 25.47 18.16 4.11 26.90 19.33 4.16
20 19.24 15.37 4.37 21.42 15.63 4.45 22.17 16.99 4.46 23.62 17.04 4.51 24.35 18.41 4.53 25.81 18.34 4.58 27.28 19.53 4.62
25 19.42 15.38 5.19 21.64 15.64 5.27 22.39 17.00 5.29 23.86 17.05 5.35 24.60 18.43 5.37 26.07 18.36 5.43 27.55 19.55 5.48
30 19.05 14.62 5.92 21.22 14.86 6.01 21.95 16.16 6.03 23.38 16.21 6.10 24.11 17.51 6.13 25.55 17.44 6.19 27.00 18.59 6.26
35 17.38 14.28 6.60 19.35 14.61 6.70 20.02 15.89 6.74 21.35 15.93 6.81 22.00 17.21 6.84 23.32 17.14 6.91 24.65 18.26 6.98
40 17.21 13.49 6.25 19.17 13.88 6.34 19.82 15.09 6.39 21.13 15.14 6.44 21.78 16.35 6.47 23.09 16.29 6.54 24.39 17.35 6.61
46 13.70 12.22 6.09 15.27 13.13 6.17 15.78 13.91 6.21 16.81 14.32 6.27 17.35 15.47 6.31 18.39 15.40 6.37 19.42 16.39 6.43

Ceiling type
Model: ABYG30LRTE × 3
AFR
m
3
/h
4,980
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 17.51 2.75 22.49 17.62 2.79 23.25 19.15 2.81 24.78 19.22 2.84 25.55 20.75 2.85 27.08 20.66 2.89 28.62 22.02 2.91
-10 19.98 17.33 2.76 22.27 17.44 2.80 23.02 18.97 2.81 24.55 19.02 2.84 25.30 20.54 2.86 26.82 20.46 2.89 28.34 21.79 2.91
0 19.80 17.17 2.94 22.05 17.28 2.98 22.80 18.78 3.00 24.30 18.84 3.03 25.05 20.34 3.05 26.57 20.26 3.07 28.07 21.58 3.10
5 19.75 17.13 3.06 22.01 17.23 3.11 22.75 18.73 3.13 24.25 18.79 3.16 25.01 20.29 3.18 26.51 20.21 3.21 28.01 21.53 3.24
10 19.55 17.10 3.45 21.78 17.21 3.50 22.51 18.70 3.52 24.00 18.77 3.55 24.74 20.26 3.57 26.23 20.19 3.61 27.71 21.50 3.65
15 18.99 16.90 3.56 21.14 17.18 3.62 21.87 18.67 3.64 23.30 18.73 3.67 24.02 20.23 3.70 25.47 20.15 3.73 26.90 21.46 3.77
20 19.24 17.06 3.97 21.42 17.35 4.03 22.17 18.86 4.04 23.62 18.91 4.09 24.35 20.44 4.11 25.81 20.35 4.15 27.28 21.67 4.19
25 19.42 17.07 4.71 21.64 17.36 4.78 22.39 18.87 4.80 23.86 18.93 4.85 24.60 20.45 4.87 26.07 20.37 4.92 27.55 21.70 4.97
30 19.05 16.22 5.37 21.22 16.49 5.45 21.95 17.94 5.47 23.38 17.99 5.54 24.11 19.43 5.56 25.55 19.35 5.61 27.00 20.63 5.67
35 17.38 15.85 5.99 19.35 16.21 6.08 20.02 17.63 6.11 21.35 17.68 6.18 22.00 19.10 6.20 23.32 19.02 6.27 24.65 20.26 6.33
40 17.21 14.97 5.67 19.17 15.40 5.75 19.82 16.75 5.79 21.13 16.80 5.84 21.78 18.15 5.87 23.09 18.08 5.93 24.39 19.25 5.99
46 13.70 13.57 5.53 15.27 14.57 5.60 15.78 15.44 5.63 16.81 15.90 5.69 17.35 17.17 5.72 18.39 17.09 5.78 19.42 18.19 5.83
- 161 -
6-2. Model: AOYG90LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA

Fujitsu ABYG36LRTE Specifications

General

Cooling Capacity	10.0 kW
Heating Capacity	11.2 kW
Seasonal Energy Efficiency Ratio (SEER)	6.1
Refrigerant	R410A
Power Supply	50 Hz
Outdoor Unit Noise Level	53 dB(A)
