¢ Model: ARYG36LMLE (Static pressure mode 3)
Static pressure (Pa)
55 63 77 89 102 117 130 150
Fan
speed
HIGH
m3/h — — — — — — 1,730 1,500
l/s — — — — — — 481 417
CFM — — — — — — 1,018 883
MED
m3/h — — — — 1,530 1,310 — —
l/s — — — — 425 364 — —
CFM — — — — 901 771 — —
LOW
m3/h — — 1,330 1,140 — — — —
l/s — — 369 317 — — — —
CFM — — 783 671 — — — —
QUIET
m3/h 1,110 960 — — — — — —
l/s 308 267 — — — — — —
CFM 653 565 — — — — — —
Airflow (m
3
/h)
60
150
130
Static pressure (Pa)
900 1,100 1,500 1,700 1,900 2,100 2,300
Q-h Characteristic curve
1,300
50
140
100
90
70
80
120
110
Low
Quiet
Med
Hi
- 85 -
6-2. Duct type 6. Fan performance
INDOOR UNITS SIMULTANEOUS MULTI INDOOR UNITS SIMULTANEOUS MULTI

Fujitsu ABYG36LRTE Specifications

General

Cooling Capacity	10.0 kW
Heating Capacity	11.2 kW
Seasonal Energy Efficiency Ratio (SEER)	6.1
Refrigerant	R410A
Power Supply	50 Hz
Outdoor Unit Noise Level	53 dB(A)
