Fujitsu ADUH12LUAS1 User Manual

MODEL: ADUH24LUAS1
Outdoor temperature
Indoor temperature (°FDB)
60.0 65.0 70.0 75.0 78.0
(°FDB) (°FWB) TC TC TC TC TC
5.0 3.0 17.66 17.24 16.82 16.40 15.98
14.0 12.0 19.92 19.44 18.97 18.49 18.02
23.0 19.0 22.17 21.64 21.11 20.59 20.06
32.0 28.0 25.83 25.21 24.60 23.98 23.37
41.0 37.0 29.49 28.79 28.08 27.38 26.68
47.0 43.0 30.24 29.52 28.80 28.08 27.36
50.0 47.0 30.24 29.52 28.80 28.08 27.36
59.0 50.0 30.24 29.52 28.80 28.08 27.36
68.0 59.0 28.86 28.17 27.49 26.80 26.11
75.0 65.0 27.51 26.85 26.20 25.54 24.89
- 283 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ

Fujitsu ADUH12LUAS1 Specifications

General

Cooling Capacity	3.5 kW
Cooling Capacity (BTU)	12000 BTU
Refrigerant	R410A
Indoor Unit Dimensions (W x H x D)	790 x 275 x 215 mm
Outdoor Unit Dimensions (W x H x D)	800 x 540 x 290 mm
Weight (Indoor Unit)	9 kg
Indoor Unit Weight	9 kg
Type	Split System
Power Supply	Single Phase
