1. Compressor frequency control
1-1. Cooling operation
A sensor (room temperature thermistor) built in the indoor unit body will usually perceive difference
or variation between a set temperature and present room temperature, and controls the operation
frequency of the compressor.
• If the room temperature is 11 °F (6.0 °C) higher than a set temperature, the compressor operation
frequency will attain to maximum performance.
• If the room temperature is 2 °F (1.0 °C) lower than a set temperature, the compressor will be
stopped.
• →hen the room temperature is within the range of +11 °F (6.0 °C) to -2 °F (1.0 °C) of the setting
temperature, the compressor frequency is controlled within the range shown in the table below.
However, the maximum frequency is limited in the range shown in the figure below based on the
indoor fan mode and the outdoor temperature.
• Compressor frequency range
Unit: rps
Model name Minimum frequency Maximum frequency
ADUH09LUAS1 12 72
ADUH12LUAS1
ADUH18LUAS1
8 102
1-1. Cooling operation - (04-1) - 1. Compressor frequency control
