5. CONTROL SYSTEM
When the cable is buried in the wall

Remove the material (thinner than the surrounding material) in the wiring hole in the remote îž”
sensor using a pair of cutters.
Drill a hole in the wall for the cable.îž”
Seal the area around the cable penetration with putty.îž”
20
ø6 - ø10
20
55
1
Screw
(M4 x 16mm)
Mounting hole dimensions
[Unit : mm]
Finish

Fit the cover on the remote sensor and screw it in place.îž”
DIMENSIONS

55.2
70.2
PACKING LIST

Name and shape Quantity
Application
Installation manual
1
Cable (10m)
1
Screw
(M4 x 16mm)
2
Screw
(M4 x 10mm)
2
Cord clamp
1
- (05 - 52) -
CONTROL
SYSTEM
CONTROL
SYSTEM
