¢ Floor type
 Unit: kBtu/h, °F
• TC: Total Capacity (kBtu/h).
• The data is based on the following conditions:
Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: AGU9RLF
Outdoor temperature
Indoor temperature (°FDB)
60.0 65.0 70.0 75.0 78.0
(°FDB) (°FWB) TC TC TC TC TC
5.0 3.0 6.62 6.47 6.31 6.15 5.99
14.0 12.0 7.47 7.29 7.11 6.94 6.76
23.0 19.0 8.31 8.12 7.92 7.72 7.52
32.0 28.0 9.69 9.46 9.22 8.99 8.76
41.0 37.0 11.06 10.80 10.53 10.27 10.01
47.0 43.0 11.34 11.07 10.80 10.53 10.26
50.0 47.0 11.34 11.07 10.80 10.53 10.26
59.0 50.0 11.34 11.07 10.80 10.53 10.26
68.0 59.0 10.82 10.56 10.31 10.05 9.79
75.0 65.0 10.32 10.07 9.82 9.58 9.33
MODEL: AGU12RLF
Outdoor temperature
Indoor temperature (°FDB)
60.0 65.0 70.0 75.0 78.0
(°FDB) (°FWB) TC TC TC TC TC
5.0 3.0 8.83 8.62 8.41 8.20 7.99
14.0 12.0 9.96 9.72 9.48 9.25 9.01
23.0 19.0 11.08 10.82 10.56 10.29 10.03
32.0 28.0 12.91 12.61 12.30 11.99 11.68
41.0 37.0 14.74 14.39 14.04 13.69 13.34
47.0 43.0 15.12 14.76 14.40 14.04 13.68
50.0 47.0 15.12 14.76 14.40 14.04 13.68
59.0 50.0 15.12 14.76 14.40 14.04 13.68
68.0 59.0 14.43 14.09 13.74 13.40 13.06
75.0 65.0 13.75 13.43 13.10 12.77 12.44
MODEL: AGU15RLF
Outdoor temperature
Indoor temperature (°FDB)
60.0 65.0 70.0 75.0 78.0
(°FDB) (°FWB) TC TC TC TC TC
5.0 3.0 11.04 10.78 10.51 10.25 9.99
14.0 12.0 12.45 12.15 11.85 11.56 11.26
23.0 19.0 13.86 13.53 13.20 12.87 12.54
32.0 28.0 16.14 15.76 15.37 14.99 14.61
41.0 37.0 18.43 17.99 17.55 17.11 16.68
47.0 43.0 18.90 18.45 18.00 17.55 17.10
50.0 47.0 18.90 18.45 18.00 17.55 17.10
59.0 50.0 18.90 18.45 18.00 17.55 17.10
68.0 59.0 18.04 17.61 17.18 16.75 16.32
75.0 65.0 17.19 16.78 16.37 15.96 15.55
- 292 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ
