Fujitsu AMUG24LMAS Design & Technical Manual

¢ Model: AMUG48LMAS
AFR CFM 1,640
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
14 33.48 30.60 2.58 39.83 33.85 2.64 45.19 37.02 2.77 50.60 40.61 2.97 55.54 44.28 3.20 60.88 48.60 3.53
32 34.47 31.83 3.13 42.89 38.15 3.18 49.17 41.94 3.29 54.70 42.63 3.48 59.22 50.42 3.66 60.33 48.23 3.96
41 34.82 32.27 3.40 43.72 39.33 3.46 50.19 43.20 3.57 55.63 43.00 3.75 59.91 51.96 3.91 59.70 47.91 4.19
50 35.08 32.60 3.67 44.11 39.85 3.74 50.53 43.82 3.86 55.81 42.96 4.03 59.85 52.49 4.17 59.85 47.58 4.43
59 35.21 32.79 3.94 44.02 39.74 4.03 50.26 43.33 4.15 55.24 42.47 4.33 59.00 51.98 4.45 57.72 47.03 4.68
67 35.26 32.87 4.18 43.57 39.09 4.29 49.48 42.37 4.42 54.11 41.70 4.59 57.62 50.69 4.71 56.55 46.53 4.91
77 35.20 32.83 4.49 42.48 37.55 4.62 47.75 40.24 4.78 51.84 40.23 4.94 55.01 47.90 5.06 54.79 45.81 5.21
86 35.03 32.68 4.76 41.01 35.49 4.92 45.52 37.50 5.10 49.02 38.47 5.26 51.87 44.32 5.38 52.96 45.07 5.48
95 34.93 32.48 5.03 39.14 32.75 5.28 42.45 34.10 5.45 45.60 36.45 5.56 48.13 39.80 5.70 50.77 44.19 5.74
104 34.40 32.01 5.31 36.70 29.41 5.55 39.12 29.60 5.79 41.12 33.68 5.94 43.27 34.10 6.08 48.60 43.33 6.07
115 33.82 31.36 5.64 33.17 24.44 5.94 33.94 23.21 6.22 34.83 29.91 6.37 36.53 25.85 6.53 45.46 42.10 6.45
AFR
m
3
/h
2,786
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10 9.81 8.97 2.58 11.67 9.92 2.64 13.24 10.85 2.77 14.83 11.90 2.97 16.28 12.98 3.20 17.84 14.24 3.53
0 10.10 9.33 3.13 12.57 11.18 3.18 14.41 12.29 3.29 16.03 12.49 3.48 17.36 14.78 3.66 17.68 14.14 3.96
5 10.21 9.46 3.40 12.82 11.53 3.46 14.71 12.66 3.57 16.30 12.60 3.75 17.56 15.23 3.91 17.50 14.04 4.19
10 10.28 9.55 3.67 12.93 11.68 3.74 14.81 12.84 3.86 16.36 12.59 4.03 17.54 15.38 4.17 17.54 13.94 4.43
15 10.32 9.61 3.94 12.90 11.65 4.03 14.73 12.70 4.15 16.19 12.45 4.33 17.29 15.23 4.45 16.92 13.78 4.68
19.4 10.33 9.63 4.18 12.77 11.46 4.29 14.50 12.42 4.42 15.86 12.22 4.59 16.89 14.86 4.71 16.57 13.64 4.91
25 10.32 9.62 4.49 12.45 11.01 4.62 13.99 11.79 4.78 15.19 11.79 4.94 16.12 14.04 5.06 16.06 13.43 5.21
30 10.27 9.58 4.76 12.02 10.40 4.92 13.34 10.99 5.10 14.37 11.28 5.26 15.20 12.99 5.38 15.52 13.21 5.48
35 10.24 9.52 5.03 11.47 9.60 5.28 12.44 9.99 5.45 13.36 10.68 5.56 14.11 11.66 5.70 14.88 12.95 5.74
40 10.08 9.38 5.31 10.76 8.62 5.55 11.46 8.68 5.79 12.05 9.87 5.94 12.68 9.99 6.08 14.24 12.70 6.07
46.1 9.91 9.19 5.64 9.72 7.16 5.94 9.95 6.80 6.22 10.21 8.77 6.37 10.71 7.58 6.53 13.32 12.34 6.45
- 9 -
3-1. Cooling capacity 3. Capacity table
DUCT TYPE AMUG24-48LMAS DUCT TYPE AMUG24-48LMAS
