Fujitsu AMUG24LMAS Design & Technical Manual

6-2. Models: AOUG36LMAS1 and AOUG48LMAS1
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length
m
5 7.5 10 20 30 40 50 60 70
ft 16 24 32 65 98 131 164 196 229
Height difference H
Indoor unit is higher
than outdoor unit *1
30 98 — — — — 0.885 0.842 0.800 0.754 0.711
20 65 — — — 0.937 0.895 0.852 0.810 0.770 0.728
10 32 — — 0.990 0.947 0.905 0.862 0.822 0.780 0.738
7.5 24 — 0.993 0.993 0.950 0.908 0.865 0.824 0.782 0.740
5 16 0.995 0.995 0.995 0.952 0.910 0.867 0.825 0.779 0.736
0 0 1.000 1.000 1.000 0.957 0.915 0.872 0.830 0.784 0.741
Indoor unit is lower
than outdoor unit *2
-5 -16 1.000 1.000 1.000 0.957 0.915 0.872 0.830 0.784 0.741
-7.5 -24 — 1.000 1.000 0.957 0.915 0.872 0.830 0.784 0.741
-10 -32 — 1.000 0.957 0.915 0.872 0.830 0.784 0.741
-20 -65 — — — 0.957 0.915 0.872 0.830 0.784 0.741
-30 -98 — — — — 0.915 0.872 0.830 0.784 0.741
HEATING
Pipe length
m
5 7.5 10 20 30 40 50 60 70
ft 16 24 32 65 98 131 164 196 229
Height difference H
Indoor unit is higher
than outdoor unit *1
30 98 — — — — 0.995 0.993 0.990 0.853 0.828
20 65 — — — 0.998 0.995 0.993 0.990 0.853 0.828
10 32 — — 1.000 0.998 0.995 0.993 0.990 0.853 0.828
7.5 24 — 1.000 1.000 0.998 0.995 0.993 0.990 0.853 0.828
5 16 1.000 1.000 1.000 0.998 0.995 0.993 0.990 0.853 0.828
0 0 1.000 1.000 1.000 0.998 0.995 0.993 0.990 0.853 0.828
Indoor unit is lower
than outdoor unit *2
-5 -16 1.000 1.000 0.995 0.993 0.990 0.988 0.985 0.848 0.823
-7.5 -24 — 1.000 0.992 0.990 0.987 0.985 0.982 0.845 0.820
-10 -32 — — 0.990 0.988 0.985 0.983 0.980 0.843 0.818
-20 -65 — — — 0.978 0.975 0.973 0.970 0.833 0.808
-30 -98 — — — — 0.965 0.963 0.960 0.823 0.798
- 82 -
6-2. Models: AOUG36LMAS1 and AOUG48LMAS1 6. Capacity compensation rate for pipe length and height difference
OUTDOOR UNIT AOU24-30RGLX, AOUG36-48LMAS1 OUTDOOR UNIT AOU24-30RGLX, AOUG36-48LMAS1
