Fujitsu AMUG30LMAS Design & Technical Manual

¢ Model: AMUG30LMAS
AFR CFM 870
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-5 6.78 6.78 3.78 7.07 7.07 3.97 7.56 7.56 4.07 8.06 8.06 4.28 9.43 9.43 4.30 10.12 10.12 4.34
5 13.61 13.61 2.96 13.96 13.96 3.15 14.82 14.82 3.27 16.17 16.17 3.36 17.96 17.96 3.40 20.31 20.31 3.40
14 18.72 16.52 2.37 20.07 16.98 2.56 21.37 17.80 2.69 22.83 19.06 2.80 24.38 20.55 2.88 26.13 22.53 2.93
32 26.19 20.80 1.58 29.02 21.43 1.76 31.01 22.21 1.90 32.63 23.28 2.04 33.84 24.39 2.16 34.72 25.83 2.27
41 28.54 22.16 1.37 31.86 22.86 1.54 34.08 23.64 1.69 35.77 24.61 1.82 36.88 25.63 1.96 37.50 26.89 2.09
50 29.96 23.01 1.30 33.61 23.77 1.46 36.00 24.54 1.59 37.74 25.44 1.73 38.80 26.42 1.86 39.26 27.57 2.00
59 30.47 23.35 1.35 34.28 24.14 1.49 36.76 24.92 1.62 38.53 25.75 1.75 39.59 26.76 1.88 40.00 27.86 2.01
67 30.15 23.22 1.51 33.97 24.03 1.63 36.46 24.83 1.74 38.27 25.60 1.86 39.35 26.69 1.97 39.81 27.79 2.10
77 28.71 22.48 1.85 32.35 23.30 1.95 34.79 24.12 2.04 36.61 24.83 2.13 37.80 26.09 2.22 38.43 27.27 2.31
86 26.44 21.27 2.29 29.76 22.09 2.37 32.06 22.95 2.43 33.89 23.59 2.49 35.21 25.07 2.55 36.12 26.39 2.61
95 23.26 19.55 2.87 26.08 20.34 2.91 28.17 21.24 2.94 30.00 21.85 2.97 31.50 23.61 2.99 32.80 25.13 3.00
104 19.15 17.31 3.57 21.31 18.07 3.58 23.13 19.02 3.60 24.94 19.59 3.61 26.67 21.69 3.62 28.46 23.47 3.63
115 12.89 12.89 4.60 14.02 14.02 4.61 15.40 15.40 4.63 17.17 16.13 4.64 19.25 18.74 4.65 21.79 20.93 4.67
AFR
m
3
/h
1,478
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-20.6 1.99 1.99 3.78 2.07 2.07 3.97 2.22 2.22 4.07 2.36 2.36 4.28 2.77 2.77 4.30 2.97 2.97 4.34
-15 3.99 3.99 2.96 4.09 4.09 3.15 4.34 4.34 3.27 4.74 4.74 3.36 5.26 5.26 3.40 5.95 5.95 3.40
-10 5.49 4.84 2.37 5.88 4.98 2.56 6.26 5.22 2.69 6.69 5.58 2.80 7.14 6.02 2.88 7.66 6.60 2.93
0 7.68 6.09 1.58 8.50 6.28 1.76 9.09 6.51 1.90 9.56 6.82 2.04 9.92 7.15 2.16 10.18 7.57 2.27
5 8.36 6.50 1.37 9.34 6.70 1.54 9.99 6.93 1.69 10.48 7.21 1.82 10.81 7.51 1.96 10.99 7.88 2.09
10 8.78 6.74 1.30 9.85 6.97 1.46 10.55 7.19 1.59 11.06 7.46 1.73 11.37 7.74 1.86 11.51 8.08 2.00
15 8.93 6.84 1.35 10.05 7.07 1.49 10.77 7.30 1.62 11.29 7.55 1.75 11.60 7.84 1.88 11.72 8.16 2.01
19.4 8.84 6.81 1.51 9.96 7.04 1.63 10.69 7.28 1.74 11.22 7.50 1.86 11.53 7.82 1.97 11.67 8.14 2.10
25 8.41 6.59 1.85 9.48 6.83 1.95 10.20 7.07 2.04 10.73 7.28 2.13 11.08 7.65 2.22 11.26 7.99 2.31
30 7.75 6.23 2.29 8.72 6.47 2.37 9.40 6.72 2.43 9.93 6.91 2.49 10.32 7.35 2.55 10.59 7.73 2.61
35 6.82 5.73 2.87 7.64 5.96 2.91 8.26 6.23 2.94 8.79 6.40 2.97 9.23 6.92 2.99 9.61 7.36 3.00
40 5.61 5.07 3.57 6.25 5.30 3.58 6.78 5.58 3.60 7.31 5.74 3.61 7.82 6.36 3.62 8.34 6.88 3.63
46.1 3.78 3.78 4.60 4.11 4.11 4.61 4.51 4.51 4.63 5.03 4.73 4.64 5.64 5.49 4.65 6.39 6.13 4.67
¢ Model: AMUG36LMAS
AFR CFM 1,200
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
14 26.43 24.18 1.48 31.44 26.75 1.51 35.68 29.26 1.58 39.95 32.10 1.70 43.85 34.99 1.83 48.06 38.41 2.02
32 27.21 25.15 1.79 33.86 30.15 1.82 38.82 33.15 1.88 43.19 33.69 1.99 46.75 39.85 2.09 47.63 38.12 2.27
41 27.49 25.50 1.94 34.52 31.08 1.98 39.62 34.14 2.04 43.92 33.99 2.15 47.30 41.07 2.24 47.13 37.87 2.40
50 27.70 25.76 2.10 34.82 31.49 2.14 39.89 34.63 2.21 44.06 33.95 2.31 47.25 41.48 2.39 47.25 37.60 2.53
59 27.80 25.91 2.26 34.75 31.40 2.30 39.68 34.24 2.37 43.61 33.57 2.48 46.58 41.08 2.55 45.57 37.17 2.68
67 27.83 25.98 2.39 34.40 30.90 2.45 39.06 33.48 2.53 42.72 32.95 2.63 45.49 40.06 2.69 44.65 36.78 2.81
77 27.79 25.95 2.57 33.53 29.68 2.64 37.70 31.80 2.73 40.93 31.80 2.83 43.43 37.85 2.89 43.26 36.20 2.98
86 27.66 25.83 2.72 32.38 28.05 2.82 35.94 29.63 2.92 38.70 30.41 3.01 40.95 35.03 3.08 41.81 35.62 3.14
95 27.58 25.67 2.88 30.90 25.88 3.02 33.51 26.95 3.12 36.00 28.81 3.18 38.00 31.45 3.26 40.08 34.92 3.28
104 27.16 25.29 3.04 28.98 23.25 3.17 30.88 23.40 3.31 32.46 26.61 3.39 34.16 26.95 3.48 38.37 34.24 3.47
115 26.70 24.78 3.23 26.19 19.31 3.40 26.79 18.34 3.56 27.50 23.64 3.64 28.84 20.43 3.74 35.89 33.27 3.69
AFR
m
3
/h
2,039
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10 7.75 7.09 1.48 9.22 7.84 1.51 10.46 8.57 1.58 11.71 9.41 1.70 12.85 10.26 1.83 14.09 11.26 2.02
0 7.98 7.37 1.79 9.92 8.84 1.82 11.38 9.71 1.88 12.66 9.87 1.99 13.70 11.68 2.09 13.96 11.17 2.27
5 8.06 7.47 1.94 10.12 9.11 1.98 11.61 10.01 2.04 12.87 9.96 2.15 13.86 12.04 2.24 13.81 11.10 2.40
10 8.12 7.55 2.10 10.21 9.23 2.14 11.69 10.15 2.21 12.91 9.95 2.31 13.85 12.16 2.39 13.85 11.02 2.53
15 8.15 7.60 2.26 10.19 9.20 2.30 11.63 10.04 2.37 12.78 9.84 2.48 13.65 12.04 2.55 13.36 10.89 2.68
19.4 8.16 7.61 2.39 10.08 9.06 2.45 11.45 9.81 2.53 12.52 9.66 2.63 13.33 11.74 2.69 13.08 10.78 2.81
25 8.14 7.61 2.57 9.83 8.70 2.64 11.05 9.32 2.73 12.00 9.32 2.83 12.73 11.09 2.89 12.68 10.61 2.98
30 8.11 7.57 2.72 9.49 8.22 2.82 10.53 8.69 2.92 11.34 8.91 3.01 12.00 10.27 3.08 12.26 10.44 3.14
35 8.08 7.52 2.88 9.06 7.59 3.02 9.82 7.90 3.12 10.55 8.44 3.18 11.14 9.22 3.26 11.75 10.24 3.28
40 7.96 7.41 3.04 8.49 6.81 3.17 9.05 6.86 3.31 9.51 7.80 3.39 10.01 7.90 3.48 11.24 10.04 3.47
46.1 7.82 7.26 3.23 7.67 5.66 3.40 7.85 5.38 3.56 8.06 6.93 3.64 8.45 5.99 3.74 10.52 9.75 3.69
- 8 -
3-1. Cooling capacity 3. Capacity table
DUCT TYPE AMUG24-48LMAS DUCT TYPE AMUG24-48LMAS
