Installation space requirement
Provide sufficient installation space for product safety.
(Top side)
24 (600)
or more
Service access
4 (100)
or more
For installation method, the following 4 patterns
• Pattern A: Vertical installation, air intake port at the bottom
• Pattern B: Horizontal installation, air intake port at the right
2-1. Indoor unit
- (01-6) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
