08-15
J
U
M
P
ER
W
IRE S
ETT
I
NG
E
X
T
E
R
N
A
L
I
N
P
U
T
A
N
D
O
U
T
P
U
T
Commercial mode setting
( Factory setting)
JM2 JM state
Connect Residencial
Disconnect Commercial
Fan delay setting
( Factory setting)
JM3 JM state
Connect Invalidity
Disconnect Validity
Connector INPUT OUTPUT REMARKS
CN114
CONTROL INPUT
(OPERATION/STOP)
-
CN115 - OPERATION DISPLAY
CN14 - FRESH AIR
CN15 - ELECTRICAL HEATER
See external
input/output settings
for details.
"Hot start" can be canceled,fan operates continously when indoor unit is ON on every mode.
When you select "FAN:AUTO"mode fan goes in "HIGH"
This setting can be used when the auxiliary heater is mounted.
When the fan operation is stopped when the indoor unit is operating with an auxiliary heater,
the fan operation continues one minutes.
Room temperature correct coefficient of cooling
Decide the cooling temperature correct coefficient value of cooling.
( Factory setting)
JM1 JM state
Connect 0 deg
Disconnect + 2 deg
Cool temperature corrction
