03-01
Ø12.7mm(1/2")
Ø6.35mm(1/4")
3. REFRIGERANT CIRCUIT
MODEL : AR*18LUAD / AO*18LMAKL
Outdoor Unit Indoor Unit
CONDENSER EVAPOLATOR
HIGH
PRESSURE
SWITCH
THO
THO
THPO
THD
THR
THR
THPI
THPI
THD
THPO
COMPRESSOR
ACCUMULATOR
EXPANSION
VALVE
STRAINER
MUFFLER
4-Way
valve
THERMISTOR(DISCHARGE TEMP.)
THERMISTOR(ROOM TEMP.)
THERMISTOR(PIPE TEMP.)
THERMISTOR(OUTDOOR TEMP.)
THERMISTOR(PIPE TEMP.)
Refrigerant Pipe
Refrigerant Pipe
COOL
HEAT
Ø15.88mm(5/8")
Ø9.52mm(3/8")
MODEL : AR*24LUAN / AO*24LMAKL
Outdoor Unit Indoor Unit
CONDENSER EVAPOLATOR
HIGH
PRESSURE
SWITCH
THO
THO
THPO
THD
THR
THR
THPI
THPI
THD
THPO
COMPRESSOR
ACCUMULATOR
EXPANSION
VALVE
STRAINER
MUFFLER
4-Way
valve
THERMISTOR(DISCHARGE TEMP.)
THERMISTOR(ROOM TEMP.)
THERMISTOR(PIPE TEMP.)
THERMISTOR(OUTDOOR TEMP.)
THERMISTOR(PIPE TEMP.)
Refrigerant Pipe
Refrigerant Pipe
COOL
HEAT
