Fujitsu AO 45LJBYL Series User Manual

08-01
MODEL : AR*18LUAD/ AO*18LMAKL
COOLING
HEATING
8-1. CAPACITY TABLE
8. APPENDING DATA
AFR 17.3
(°CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
0 3.63 3.05 0.30 3.70 2.88 0.31 3.77 3.05 0.31 3.88 3.17 0.32 3.93 3.15 0.32 4.01 3.09 0.32 4.05 3.06 0.32 4.09 3.19 0.33
5 3.73 3.12 0.38 3.82 2.96 0.39 3.91 3.15 0.39 4.05 3.31 0.40 4.10 3.29 0.40 4.20 3.24 0.41 4.25 3.22 0.41 4.29 3.36 0.42
10 4.42 3.70 0.60 4.53 3.51 0.62 4.64 3.74 0.62 4.83 3.95 0.64 4.91 3.93 0.64 5.04 3.89 0.65 5.10 3.86 0.66 5.15 4.04 0.66
15 4.16 3.46 0.67 4.26 3.27 0.68 4.37 3.51 0.69 4.55 3.71 0.70 4.62 3.70 0.71 4.75 3.67 0.72 4.81 3.65 0.73 4.87 3.82 0.73
20 4.08 3.38 0.76 4.17 3.20 0.77 4.27 3.42 0.78 4.43 3.62 0.79 4.50 3.61 0.80 4.63 3.58 0.81 4.70 3.56 0.82 4.75 3.74 0.82
25 5.28 4.40 1.24 5.41 4.17 1.25 5.53 4.44 1.26 5.74 4.69 1.28 5.83 4.67 1.29 5.99 4.62 1.30 6.06 4.60 1.31 6.13 4.82 1.32
30 5.04 4.18 1.39 5.19 3.98 1.40 5.31 4.25 1.41 5.50 4.50 1.44 5.59 4.49 1.45 5.76 4.45 1.47 5.84 4.43 1.47 5.91 4.65 1.48
35 5.35 4.41 1.92 5.45 4.16 1.93 5.59 4.47 1.95 5.80 4.74 1.98 5.90 4.73 1.99 6.09 4.70 2.02 6.18 4.68 2.03 6.27 4.94 2.04
40 5.04 4.15 2.14 5.11 3.89 2.15 5.23 4.18 2.16 5.44 4.45 2.19 5.55 4.45 2.21 5.74 4.43 2.24 5.83 4.42 2.26 5.93 4.68 2.28
43 4.79 3.92 2.21 4.87 3.69 2.22 4.99 3.98 2.23 5.20 4.26 2.26 5.31 4.26 2.28 5.50 4.24 2.32 5.61 4.24 2.33 5.71 4.51 2.34
Indoor temperature
18°CDB
21°CDB
23°CDB
26°CDB
27°CDB
29°CDB
30°CDB
32°CDB
23°CWB
12°CWB
15°CWB
16°CWB
18°CWB
19°CWB
21°CWB
22°CWB
Outdoor temperature
AFR 17.3
(°CDB) (°CWB) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
-10 -11 5.77 2.45 5.68 2.53 5.50 2.60 5.32 2.68 5.23 2.72 5.06 2.80 4.88 2.84
-5 -6 5.67 2.46 5.59 2.53 5.43 2.60 5.27 2.67 5.19 2.71 5.03 2.78 4.87 2.82
0 -1 5.91 2.42 5.83 2.49 5.69 2.55 5.54 2.61 5.46 2.64 5.32 2.71 5.17 2.74
2 1 6.09 2.51 6.03 2.56 5.90 2.62 5.78 2.67 5.72 2.70 5.59 2.75 5.47 2.78
7 6 7.73 2.30 7.65 2.35 7.50 2.40 7.35 2.45 7.28 2.47 7.13 2.52 6.98 2.54
10 8 8.03 2.36 7.96 2.41 7.81 2.45 7.67 2.50 7.59 2.52 7.45 2.57 7.30 2.59
15 12 8.23 2.40 8.15 2.45 8.01 2.49 7.86 2.54 7.78 2.56 7.63 2.61 7.49 2.63
20 15 8.39 2.35 8.30 2.40 8.14 2.45 7.98 2.49 7.90 2.52 7.74 2.57 7.57 2.59
24 18 8.51 2.30 8.43 2.35 8.25 2.40 8.08 2.45 7.99 2.48 7.81 2.53 7.64 2.55
30°CDB
Outdoor temperature
Indoor temperature
16°CDB
18°CDB
20°CDB
23°CDB
25°CDB
27°CDB
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
