MODEL : AR*24LUAN/ AO*24LMAKL
COOLING
MODEL : AR*30LUAN/ AO*30LMAWL
COOLING
HEATING
HEATING
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
AFR 24.8
(°CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
0 4.92 4.28 0.45 5.02 4.04 0.46 5.12 4.27 0.46 5.26 4.44 0.47 5.33 4.41 0.47 5.44 4.33 0.48 5.49 4.29 0.48 5.54 4.47 0.48
5 5.06 4.37 0.57 5.17 4.14 0.58 5.30 4.41 0.59 5.49 4.63 0.60 5.56 4.61 0.60 5.70 4.54 0.61 5.76 4.50 0.61 5.82 4.70 0.62
10 6.00 5.18 0.90 6.15 4.91 0.92 6.30 5.23 0.93 6.55 5.53 0.95 6.65 5.51 0.96 6.83 5.45 0.97 6.91 5.41 0.98 6.99 5.65 0.98
15 5.64 4.85 0.99 5.78 4.58 1.02 5.93 4.91 1.03 6.16 5.20 1.05 6.26 5.18 1.06 6.44 5.13 1.07 6.52 5.10 1.08 6.60 5.35 1.09
20 5.53 4.74 1.12 5.65 4.47 1.14 5.79 4.79 1.15 6.01 5.07 1.18 6.11 5.06 1.19 6.28 5.01 1.21 6.37 4.99 1.22 6.45 5.24 1.23
25 7.16 6.16 1.84 7.34 5.83 1.86 7.50 6.22 1.88 7.78 6.57 1.90 7.90 6.54 1.92 8.12 6.47 1.94 8.22 6.44 1.95 8.31 6.74 1.96
30 6.84 5.85 2.07 7.03 5.57 2.09 7.19 5.96 2.10 7.46 6.30 2.14 7.59 6.28 2.15 7.81 6.23 2.18 7.91 6.20 2.19 8.02 6.52 2.21
35 7.25 6.18 2.86 7.39 5.82 2.87 7.58 6.26 2.90 7.86 6.64 2.94 8.00 6.62 2.96 8.26 6.58 3.00 8.38 6.56 3.02 8.50 6.92 3.04
40 6.83 5.80 3.18 6.93 5.45 3.19 7.09 5.86 3.21 7.38 6.24 3.26 7.52 6.23 3.28 7.78 6.20 3.33 7.91 6.19 3.35 8.04 6.56 3.40
43 6.49 5.48 3.29 6.60 5.17 3.30 6.76 5.57 3.32 7.05 5.96 3.37 7.20 5.96 3.39 7.46 5.94 3.44 7.61 5.94 3.46 7.75 6.31 3.49
AFR 24.8
(°CDB)
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
-10 -11 6.92 2.99 6.81 3.08 6.60 3.18 6.39 3.27 6.28 3.32 6.07 3.42 5.86 3.46
-5 -6 6.80 3.00 6.71 3.09 6.52 3.18 6.33 3.26 6.23 3.31 6.04 3.40 5.85 3.44
0 -1 7.09 2.96 7.00 3.03 6.82 3.11 6.65 3.19 6.56 3.23 6.38 3.30 6.20 3.34
2 1 7.31 3.07 7.23 3.13 7.09 3.20 6.94 3.26 6.86 3.30 6.71 3.36 6.56 3.40
7 6 9.27 2.81 9.18 2.87 9.00 2.93 8.82 2.99 8.73 3.02 8.55 3.08 8.37 3.11
10 8 9.64 2.88 9.55 2.94 9.37 2.99 9.20 3.05 9.11 3.08 8.94 3.13 8.76 3.16
15 12 9.87 2.93 9.78 2.99 9.61 3.04 9.43 3.10 9.34 3.13 9.16 3.18 8.98 3.21
20 15 10.06 2.87 9.97 2.93 9.77 2.99 9.58 3.04 9.48 3.07 9.28 3.13 9.09 3.16
24 18 10.22 2.81 10.11 2.87 9.90 2.93 9.69 2.99 9.59 3.03 9.37 3.09 9.16 3.12
AFR 37
(°CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
-10 7.59 6.41 1.97 7.73 6.85 1.99 7.99 7.18 2.01 8.12 7.09 2.02 8.36 6.96 2.04 8.48 6.79 2.04 8.58 7.18 2.05
0 8.73 7.19 1.73 8.96 7.93 1.73 9.40 8.44 1.75 9.62 8.41 1.75 10.05 8.29 1.76 10.27 8.24 1.76 10.47 8.78 1.76
10 7.58 6.33 2.05 7.77 6.81 2.05 8.15 7.34 2.07 8.34 7.24 2.08 8.71 7.16 2.09 8.88 7.03 2.09 9.05 7.50 2.09
20 10.04 7.90 2.31 10.40 8.66 2.31 11.14 9.38 2.30 11.52 9.35 2.29 12.28 9.29 2.27 12.67 9.25 2.26 13.05 9.94 2.25
30 8.74 7.31 2.77 9.07 8.07 2.78 9.73 8.80 2.78 10.07 8.78 2.79 10.77 8.73 2.78 11.11 8.69 2.78 11.46 9.39 2.77
35 8.66 7.28 3.41 8.99 8.04 3.42 9.66 8.77 3.44 10.00 8.75 3.45 10.61 8.67 3.41 10.96 8.64 3.41 11.30 9.34 3.41
40 7.09 6.00 3.30 7.37 6.72 3.30 7.95 7.44 3.30 8.25 7.52 3.30 8.86 7.62 3.30 9.08 7.54 3.30 9.38 8.21 3.30
43 6.53 5.80 3.30 6.79 6.42 3.30 7.25 7.03 3.30 7.53 7.09 3.30 8.08 7.13 3.30 8.36 7.12 3.30 8.64 7.76 3.30
AFR 37
(°CDB)
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
-10 -11 7.73 2.79 7.56 2.85 7.49 3.00 7.22 3.08 6.99 3.09 6.76 3.10 6.38 3.10
-4 -6 8.87 3.02 8.69 3.08 8.44 3.09 8.02 3.09 7.77 3.11 7.52 3.12 7.11 3.11
1 -1 10.21 3.10 9.95 3.11 9.58 3.09 9.11 3.09 8.83 3.10 8.54 3.12 8.04 3.11
7 6 11.77 3.50 11.50 3.50 11.20 3.50 10.57 3.50 10.22 3.50 9.79 3.50 9.20 3.50
12 10 13.83 3.50 13.35 3.50 13.12 3.50 12.35 3.50 11.92 3.50 11.48 3.50 10.77 3.50
18 13 13.32 3.13 13.15 3.22 12.95 3.30 12.61 3.41 12.30 3.48 11.92 3.55 11.34 3.68
20 15 12.77 3.02 12.62 3.10 12.45 3.18 11.95 3.18 11.56 3.19 11.21 3.21 10.52 3.22
