Fujitsu AO 45LJBYL Series User Manual

08-04
MODEL : AR*45LUAK/ AO*45LJAYL
COOLING
MODEL : AR*54LUAK/ AO*54LJAYL
COOLING
HEATING
HEATING
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
AFR 58
( °CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
-10 13.30 10.85 2.45 13.65 11.82 2.46 14.35 12.67 2.49 14.69 12.58 2.51 15.34 12.34 2.53 15.64 12.20 2.54 15.92 13.02 2.55
0 12.33 9.99 3.08 12.62 10.94 3.10 13.20 11.78 3.14 13.49 11.68 3.16 14.07 11.48 3.18 14.33 11.36 3.19 14.59 12.23 3.20
10 11.96 9.92 3.46 12.25 10.90 3.49 12.85 11.77 3.52 13.16 11.68 3.54 13.74 11.48 3.57 14.04 11.39 3.58 14.31 12.29 3.59
20 13.97 10.70 3.53 14.41 11.69 3.53 15.31 12.64 3.52 15.78 12.60 3.52 16.74 12.54 3.50 17.19 12.49 3.48 17.66 13.41 3.47
30 12.33 9.95 4.24 12.76 10.95 4.25 13.63 11.89 4.26 14.07 11.85 4.27 14.98 11.75 4.27 15.43 11.69 4.27 15.85 12.60 4.27
35 12.30 9.94 5.13 12.73 10.94 5.16 13.54 11.86 5.13 14.00 11.82 5.15 14.76 11.67 5.12 15.19 11.60 5.13 15.60 12.51 5.15
40 10.65 9.04 5.00 10.92 9.96 5.00 11.55 10.83 5.00 11.94 10.84 5.00 12.55 10.75 5.00 12.94 10.74 5.00 13.29 11.64 5.00
43 9.77 8.65 5.00 10.13 9.62 5.00 10.80 10.52 5.00 11.18 10.49 5.00 11.77 10.35 5.00 12.12 10.30 5.00 12.46 11.18 5.00
Outdoor temperature
32 °CDB
15 °CWB 16 °CWB 18 °CWB 19 °CWB 21 °CWB 22 °CWB 23 °CWB
Indoor temperature
21 °CDB 23 °CDB 26 °CDB 27 °CDB 29 °CDB 30 °CDB
AFR 58
( °CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
-10 14.11 10.88 2.86 14.46 11.80 2.88 15.13 12.60 2.93 15.48 12.49 2.95 16.14 12.22 2.98 16.49 12.11 3.00 16.80 12.93 3.02
0 13.12 10.42 3.55 13.41 11.37 3.58 13.95 12.18 3.63 14.20 12.06 3.65 14.75 11.82 3.70 15.01 11.70 3.72 15.25 12.57 3.73
10 12.79 10.36 3.96 13.11 11.35 3.99 13.71 12.22 4.05 14.01 12.12 4.08 14.59 11.90 4.12 14.84 11.77 4.14 15.12 12.68 4.16
20 14.27 10.81 3.63 14.71 11.80 3.63 15.65 12.75 3.63 16.12 12.69 3.63 17.08 12.62 3.61 17.56 12.57 3.60 18.04 13.51 3.59
30 13.62 10.51 5.02 14.09 11.51 5.05 15.04 12.44 5.09 15.49 12.37 5.11 16.52 12.29 5.14 17.01 12.23 5.15 17.46 13.12 5.16
35 13.37 10.40 5.90 13.72 11.34 5.90 14.54 12.23 5.90 15.00 12.20 5.90 15.82 12.11 5.90 16.16 12.05 5.90 16.62 13.00 5.90
40 10.98 9.32 5.15 11.26 10.27 5.15 11.91 11.17 5.15 12.30 11.18 5.15 12.94 11.08 5.15 13.34 11.07 5.15 13.71 12.00 5.15
43 10.07 8.91 5.15 10.44 9.92 5.15 11.14 10.84 5.15 11.53 10.81 5.15 12.14 10.67 5.15 12.49 10.62 5.15 12.85 11.53 5.15
Outdoor temperature
32 °CDB
15 °CWB 16 °CWB 18 °CWB 19 °CWB 21 °CWB 22 °CWB 23 °CWB
Indoor temperature
21 °CDB 23 °CDB 26 °CDB 27 °CDB 29 °CDB 30 °CDB
58
AFR
( °CDB) ( °CWB) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
-10 -11 11.94 4.70 11.68 4.78 11.40 4.86 10.99 4.99 10.86 5.15 10.43 5.15 9.90 5.15
-4 -6 14.15 4.91 13.85 5.00 13.53 5.09 12.97 5.15 12.57 5.15 12.17 5.15 11.50 5.15
1 -1 16.30 5.15 15.88 5.15 15.45 5.15 14.71 5.15 14.15 5.15 13.68 5.15 12.91 5.15
7 6 19.03 5.15 18.45 5.15 18.00 5.15 17.18 5.15 16.48 5.15 15.74 5.15 14.76 5.15
12 10 20.07 5.15 19.47 5.15 18.85 5.15 18.06 5.15 17.30 5.15 16.68 5.15 15.60 5.15
18 13 20.99 5.15 20.55 5.15 19.91 5.15 18.98 5.15 18.35 5.15 17.64 5.15 16.46 5.15
20 15 20.68 5.15 20.12 5.15 19.69 5.15 18.78 5.15 17.98 5.15 17.36 5.15 16.27 5.15
Outdoor temperature
Indoor temperature
16 °CDB 18 °CDB 20 °CDB 23 °CDB 25 °CDB 27 °CDB 30 °CDB
58
AFR
( °CDB) ( °CWB) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
-10 -11 12.70 4.88 12.41 4.97 12.12 5.05 11.67 5.18 11.36 5.27 11.27 5.54 10.82 5.68
-4 -6 14.44 5.00 14.35 5.32 14.05 5.41 13.59 5.54 13.28 5.63 12.96 5.72 12.45 5.87
1 -1 16.59 5.23 16.21 5.33 16.30 5.67 15.76 5.82 15.39 5.90 15.01 5.90 14.10 5.90
7 6 19.66 5.65 19.35 5.78 19.00 5.90 17.98 5.90 17.39 5.90 16.82 5.90 15.61 5.90
12 10 20.07 5.15 19.47 5.15 18.85 5.15 18.06 5.15 17.30 5.15 16.68 5.15 15.60 5.15
18 13 20.99 5.15 20.55 5.15 19.91 5.15 18.98 5.15 18.35 5.15 17.64 5.15 16.46 5.15
20 15 20.68 5.15 20.12 5.15 19.69 5.15 18.78 5.15 17.98 5.15 17.36 5.15 16.27 5.15
27 °CDB 30 °CDB
Outdoor temperature
Indoor temperature
16 °CDB 18 °CDB 20 °CDB 23 °CDB 25 °CDB
