6) Static pressure (for Mini duct type, Slim duct type, and Medium static pressure duct type
(ARXH22KMTAP))
Select the appropriate static pressure according to the installation conditions.
For mini duct type:
Function number Setting value Setting description Factory setting
26
00 0 Pa
01 10 Pa
02 20 Pa
03 30 Pa
04 40 Pa
05 50 Pa
31
Standard (10 Pa: 07; 09; 12 models, 15
Pa: 14; 18 models)
♦
NOTES:
• Range of static pressure is different by model. 07, 09, 12 models are 0 to 30 Pa. 14, 18 models
are 0 to 50 Pa.
• Setting number in 07, 09, 12 models is “04 to 30”: Operation is same as that “03”.
• Setting number in 14, 18 models is “06 to 30”: Operation is same as that “05”.
• Setting number value cannot be set to 32 or more.
For slim duct type:
Function number Setting value Setting description Factory setting
26
00 0 Pa
01 10 Pa
02 20 Pa
03 30 Pa
04 40 Pa
05 50 Pa
06 60 Pa
07 70 Pa
08 80 Pa
09 90 Pa
31 Standard (25 Pa) ♦
Medium static pressure duct type (ARXH22KMTAP):
Function number Setting value Setting description Factory setting
26
03 30 Pa
04 40 Pa
05 50 Pa
06 60 Pa
07 70 Pa
08 80 Pa
09 90 Pa
10 100 Pa
11 110 Pa
12 120 Pa
13 130 Pa
14 140 Pa
15 150 Pa
31 Standard (40 Pa) ♦
32 Automatic airflow adjustment
NOTE: If the static pressure is set above maximum range, the setting is same as the maximum.
For example, The setting “160 Pa” (16) to “300 Pa” (30) is same as “150 Pa” (15).
