7) Horizontal louver direction switching for dew condensation prevention (for KE model in
Wall-mounted type only)
Automatically switches the position of the horizontal louver if the airflow direction is set at lower than
the dew condensation limit position in cooling or drying operation.
Select suitable adjustment position according to the customer’s preference.
Function number Setting value Setting description Factory setting
28
00 Adjust to dew condensation limit position ♦
01 Adjust to cooling standard position
8) Room temperature control for indoor unit sensor
NOTE: If the remote sensor unit option is selected, perform this setting.
Depending on the installed environment, correction of the room temperature sensor may be re-
quired. Select the appropriate control setting according to the installed environment.
The temperature of the room temperature sensor is corrected as follows:
Corrected temp. = Temp. of the room temp. sensor - Correction temp. value
Example of correction:
When the temperature of the room temp. sensor is 26°C and the setting value is “03”
(-1.0°C), corrected temp. will be 27°C (26°C - [-1.0°C]).
The temperature correction values show the difference from the Standard setting "00" (manufactur-
er’s recommended value).
Function number Setting value Setting description
Factory
setting
30
(For cooling)
31
(For heating)
00 Standard setting ♦
01 No correction 0.0°C
02 -0.5°C
More cooling
Less heating
03 -1.0°C
04 -1.5°C
05 -2.0°C
06 -2.5°C
07 -3.0°C
08 -3.5°C
09 -4.0°C
10 +0.5°C
Less cooling
More heating
11 +1.0°C
12 +1.5°C
13 +2.0°C
14 +2.5°C
15 +3.0°C
16 +3.5°C
17 +4.0°C
- 341 -
15-6. Function details
15. Function settings
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE
