¢ DIP switch setting
• SW100: Remote controller address setting
NOTE:
Because this setting is normally done automatically when 2-core wired remote con-
troller is installed, setting is unnecessary.
Multiple indoor units can be operated by using one wired remote controller.
Set the unit number of each indoor unit.
Remote
controller
address
DIP switch number
Factory setting
1 2 3 4
00 OFF OFF OFF OFF ♦
01 ON OFF OFF OFF
02 OFF ON OFF OFF
03 ON ON OFF OFF
04 OFF OFF ON OFF
05 ON OFF ON OFF
06 OFF ON ON OFF
07 ON ON ON OFF
08 OFF OFF OFF ON
09 ON OFF OFF ON
10 OFF ON OFF ON
11 ON ON OFF ON
12 OFF OFF ON ON
13 ON OFF ON ON
14 OFF ON ON ON
15 ON ON ON ON
NOTES:
• When connecting Polar 3-core wired remote controller, set the remote controller address
in the order of 0, 1, 2, ....., and 15.
• When different type of indoor units (such as wall-mounted type and cassette type, cas-
sette type and duct type, or other combinations) are connected using group control sys-
tem, some functions may no longer be available.
00 01 02
Remote controller address
Indoor unit
Remote controller
• SW101: Setting change prohibited
- 162 -
8-2. Compact cassette type (setting by DIP switch) 8. Function settings
SYSTEM
DESIGN
SYSTEM
DESIGN
