Fujitsu AO G36KBTB Series User Manual

¢
Slim duct type
Front viewSide view
1.5 m
2 m
1 m
Microphone
Measuring duct Measuring duct
Microphone
Set the static pressure
as rating in this area
¢
Duct type
Measuring ductMeasuring duct
Set the static pressure
as rating in this area
AIR
2 m
1.5 m
1 m
Microphone Microphone
- 48 -
8-4. Sound level check point 8. Noise level curve
INDOOR UNITS SIMUL. MULTI-SPLIT INDOOR UNITS SIMUL. MULTI-SPLIT
