Fujitsu AOTG24KMCA - Heating Capacity

- (01 - 10) -
WALL MOUNTED TYPE ASTG18-24KMCA WALL MOUNTED TYPE ASTG18-24KMCA
HEATING CAPACITY6-2.
MODEL

: ASTG18KMCA
MODEL

: ASTG22KMCA
MODEL

: ASTG24KMCA
AFR: Airow Rate (m
3
/min)
TC: Total Capacity (kW)
IP: Input Power (kW)
AFR 15.5
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 6.57 2.64 6.42 2.70 5.88 2.76 6.10 2.81 5.95 2.87
-10 -11 7.02 2.69 6.85 2.74 6.49 2.80 6.52 2.86 6.35 2.91
-5 -7 7.51 2.80 7.33 2.86 7.06 2.91 6.97 2.97 6.80 3.03
0 -2 7.68 2.82 7.50 2.87 7.32 2.93 7.13 2.99 6.95 3.05
5 3 8.27 2.87 8.07 2.93 7.88 2.99 7.68 3.05 7.48 3.10
7 6 8.72 2.98 8.51 3.04 8.30 3.10 8.09 3.16 7.89 3.22
10 8 9.01 2.57 8.79 2.62 8.58 2.68 8.36 2.73 8.15 2.78
15 10 9.03 2.12 8.82 2.16 8.70 2.21 8.39 2.25 8.17 2.29
AFR 16.7
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 6.41 2.39 6.25 2.44 6.10 2.49 5.95 2.54 5.80 2.59
-10 -11 7.30 2.94 7.13 3.00 6.70 2.67 6.78 3.13 6.61 3.19
-5 -7 8.11 3.03 7.91 3.09 7.55 2.81 7.53 3.22 7.34 3.28
0 -2 8.64 3.02 8.43 3.09 8.24 3.05 8.02 3.21 7.81 3.28
5 3 9.28 3.11 9.06 3.18 8.91 3.23 8.62 3.31 8.40 3.37
7 6 10.19 3.26 9.94 3.33 9.70 3.40 9.46 3.47 9.22 3.54
10 8 10.63 3.07 10.37 3.13 10.12 3.20 9.87 3.26 9.61 3.32
15 10 10.71 2.94 10.46 3.01 10.20 3.07 9.95 3.13 9.69 3.19
AFR 18.7
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 7.12 3.03 6.95 3.10 6.22 2.76 6.61 3.22 6.44 3.29
-10 -11 7.65 3.19 7.46 3.25 7.02 2.96 7.10 3.38 6.92 3.45
-5 -7 8.49 3.28 8.29 3.35 8.05 3.18 7.88 3.48 7.68 3.55
0 -2 9.04 3.34 8.83 3.41 8.63 3.44 8.39 3.55 8.18 3.62
5 3 10.21 3.43 9.97 3.50 9.73 3.58 9.48 3.65 9.24 3.72
7 6 11.13 3.53 10.87 3.61 10.60 3.68 10.34 3.75 10.07 3.83
10 8 11.35 3.32 11.08 3.39 10.81 3.46 10.54 3.53 10.27 3.60
15 10 11.44 3.19 11.17 3.25 10.89 3.32 10.62 3.39 10.35 3.45
