INDOOR UNIT
222012.05.10
19 Motor Band RFM
17 Motor Band
12 Casing A
9378031012
9378003019
18 Motor Band Assy 9378033016
15
Motor Mount Assy 938021600116
Bracket Motor Assy 9372037010
9372057018
14 Sirocco Fan
20 Fan Motor
13 Casing B 9372058015
9603087012
9372059029
11 Front Panel Assy 9380271000
Description Parts numberRef.
11
12
13
14
15
20
17
16
19
18
