INDOOR UNIT
232012.08.22
22 Control Box Assy
28 Terminal (Remote)
27 Terminal Bracket 9380251002
9900567002
25
Filter PCB 970827702826
Power Supply PCB 9708279015
9380254003
23
Control Box Cover Sub Assy
9380309017
24 Main PCB 9708281063
21 Seal Plate Sub Assy 9380195009
Description Parts numberRef.
21
24
27
30
29
32
23
22
28
25
26
33
34
31
35
34 Capacitor
33 Capacitor Bracket
32 Reactor Assy 9900460013
9704594013
9373155010
29 Terminal (Power) 9900568009
35 Thermistor
31 Diode (Power)
30 Terminal 9900433017
9704265012
0000292917
-- Room Thermistor 9703299254
-- Pipe Thermistor 9900558000
