– 13 –
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC1 IC MB89625RPFM-1067 1301965036
IC2 IC PST600CMT 0101461120
IC3 IC NJM7805FA 0100462081
IC4 IC S-93C46ADFJ-TB 0101919027
IC5,6 IC MC1413D 0101736013
Q1~3 Xstr DTC124EKA 0000936033
D1 Diode DAN202K 0000684019
D2,3 Diode D1F60 0000208024
C1,2,4~16,19,35
Cap. Ceramic 25V 0.1 F 0301102885
C20~22 Cap. Ceramic 50V 0.01 F 0301102830
C23~27 Cap. Ceramic 50V 1000pF 0300277096
C28~31 Cap. Elec. 25V 10 F 0300328026
C32 Cap. Elec. 16V 100 F 0301192251
C33 Cap. Elec. 25V 330 F 0301196952
R1~6,8~11,14, Res. 1/10W 10k ±5% 0201011010
15,27,31~39
R7 Res. 1/10W 10k ±1% 0200279497
R16~20 Res. 1/10W 1k ±5% 0201010747
R21 Res. 1/10W 49.9k ±1% 0200279824
R22 Res. 1/4W 750 ±5% 0200230719
R23,24 Res. 1/4W 560 ±5% 0200230689
R25 Res. 1/10W 1k ±5% 0200212746
R26 Res. 1/10W 47 ±5% 0201010426
JM1~6 Res. 0 0200230016
JM7,8 Jumper Wire 0.6 dia. 10 mm 9700025016
X1 Ceramic Resonator 0400061021
CST8.38MTW-TF01
BZ1 Buzzer PKM13EPY-4000-TF01 9701298013
CN1 Plug, PCB B3P-VH-B 0500011520
CN2 Plug, PCB 53324-1010 0501052096
CN3 Plug, PCB B5P-SHF-1AA 0500006069
CN4 Thermistor 105-503-96063 9702039028
CN5 Thermistor 105-103-86119 9700801078
CN6 Wire w/Connector 9703353017
UL1061 AWG26 L=170
CN7 Plug, PCB B09B-PASK-1 0501360092
Part No. Part No.
INDOOR UNIT [ASU9R1A / ASU12R1A]
CONTROLLER PCB ASSEMBLY (Ref. No. 236)
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC105 IC MIP0222SY0LT 0101972077
PC101 Photocoupler TLP621(D4)-GB 0000117074
D101 Diode D3SB60 0000689045
D102 Diode 1NH42 0000325028
D103 Diode D1FL20U 0000746519
D104 Diode D2FL20U 0000906500
D105 Diode D1F60 0000208024
C101,102 Cap. Plastic
0.1 F 0300304075
C103,104,110 Cap. Ceramic 0.01 F 0300031063
C105 Cap. Elec. 315V 150 F 0300256053
C106 Cap. Plastic 0.01 F 0300334010
C107 Cap. Elec. 016V 47 F 0301197447
C108 Cap. Ceramic 025V 0.1 F 0300266748
C109 Cap. Elec. 025V 330 F 0301196952
R101 Res. Cement 5W 2.2 ±5% 0200153674
R102 Res. Metal Oxide 2W 100k ±5% 0201107690
R103 Res. 1/4W 220 ±5% 0200230344
R104 Res. Metal Oxide 1W 56k ±5% 0201106662
SSR101 Relay G3MC-201PL-VD 9702430016
SSR102 Relay G3MB-202P-UTU 9703291012
K101 Relay G4A-1A-E-PS 9703454011
K102 Relay G5N-1A 9701566013
VA101~103 Varistor TNR10V221K 0000361156
SA101 Surge Absorber RAM-362LAS 0600275037
F101 Fuse UL-TSCR 3.15A-125V 0600329013
F102 Fuse TSCR 1A-250V 0600078119
T101 Switching Transformer 9701893010
ETS28AS121AG
L101 EMI Filter ELF15N011A 0400165095
SW101 Push Switch KSM0632B 9703476013
CN101 Plug, PCB B3P5-VH-B 0500011735
CN102 Plug, PCB 53406-9910 0500951048
CN103 Plug, PCB B2P3-VH-B-R 0500011766
CN104 Wire w/Connector L=200 9703350016
W101 Wire w/Terminal BLK L=150 9703348044
W104 Wire w/Terminal GRN L=130 9703348037
W102 Wire w/Terminal RED L=130 9703348020
W103 Wire w/Terminal BLU L=130 9703348013
JP101,102 Wire YEL L=150 1301974014
CR101 Capacitor 0300387016
Part No. Part No.
INDOOR UNIT [ASU9R1A / ASU12R1A]
POWER SUPPLY PCB ASSEMBLY (Ref. No. 875)
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC201 Remote Control Amplifier 0101525129
SBX1810-22
D201 Diode SLR-325VC RED 0000813259
D202 Diode SLR-325MC GRN 0000813242
D203 Diode SLR-325DC ORG 0000813235
C201 Cap. Ceramic 25V 0.1 F 0301102885
C202 Cap Elec. 25V 10 F 0300099339
Part No. Part No.
INDOOR UNIT [ASU9R1A / ASU12R1A]
INDICATOR PCB ASSEMBLY (Ref. No. 385)
ASU9R1A
ASU12R1A
