Fujitsu AOU12R1 Service Manual

– 1 –
SPECIFICATIONS
INDOOR UNIT ASU9R1A ASU12R1A
OUTDOOR UNIT AOU9R1 AOU12R1
COOLING CAPACITY
(BTU/hr)
9,400 11,800
HEATING CAPACITY 10,800 14,000
POWER SOURCE (V) 115 115
FREQUENCY (Hz) 60 60
RUNNING CURRENT (A)
COOLING 9.4 11.3
HEATING 8.6 10.9
INPUT WATTS (W)
COOLING 1,020 1,270
HEATING 910 1,230
SEER 10.5 10.5
MOISTURE REMOVAL Pts/hr (R/hr) 2.1 (1.0) 3.2 (1.5)
AIR CIRCULATION-Hi (m
3
/hr) 510 530
ELECTRICAL DATA
COMPRESSOR
FAN MOTOR
DIMENSIONS
TYPE
Hermetic type, Permanent split condenser,
2 pole, Single phase, Induction motor
CODE
806-005-42 806-955-42
115V 60Hz 115V 60Hz
REFRIGERANT R-22 (lbs.) 2.12 2.64
POWER SOURCE (V) 115 115
H I COOL/HEAT (r.p.m.) 1,320 ± 20 / 1,300 ± 20 1,350 ± 20 / 1,450 ± 20
INDOOR UNIT
MED COOL/HEAT (r.p.m.) 1,210 ± 20 / 1,200 ± 20 1,250 ± 20 / 1,260 ± 20
LO COOL/HEAT (r.p.m.) 1,100 ± 20 / 1,080 ± 20 1,150 ± 20 / 1,080 ± 20
QUIET COOL/HEAT (r.p.m.) 1,000 ± 20 / 960 ± 20 1,050 ± 20 / 960 ± 20
OUTDOOR UNIT (r.p.m.) ,835 ± 30 ,800 ± 30
INDOOR UNIT
H x W x D inch (mm)
11 (280) x 32-1/8 (815) x 7 (179)
OUTDOOR UNIT 20-7/8 (530) x 30-1/2 (750) x 9-7/8 (250)
WEIGHT
INDOOR UNIT
GROSS / NET lbs.(kg)
26 / 22 (12 / 10) 26 / 22 (12 / 10)
OUTDOOR UNIT 68 / 64 (31 / 29) 81 / 77 (37 / 35)

Fujitsu AOU12R1 Specifications

General

Brand	Fujitsu
Model	AOU12R1
Category	Air Conditioner
Language	English
