– 12 –
ASU9R1A / AOU9R1
ASU12R1A / AOU12R1
P ARTS LIST
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
INDOOR UNIT [ASU9R1A / ASU12R1A]
OUTDOOR UNIT [AOU9R1 / AOU12R1]
26 BR Sheet 40 x 80 x T5 9305039043 9305039043
32-1 Control Box-A 9309045019 9309045019
32-2 Control Box-B 9309046016 9309046016
32-3 Control Box-C 9309055018 9309055018
41 Fan Motor Assy-In 9600881019 9600881019
63 Front Panel Assy w/o Filter 9306817176 9306817176
64 Capacitor (Fan Motor) 5.7 F/200V 9700468066 9700468066
65 Flow Control Panel-Z 9306571016 9306571016
69 Louver-A 9306583019 9306583019
74 Filter 9306601010 9306601010
89 Casing Fixture Metal 9307018008 9307018008
92 Link Plate 9306577018 9306577018
93 Link-A 9306573010 9306573010
94 Link-B 9306574017 9306574017
95 Link-C 9306575014 9306575014
96 Link-D 9306576011 9306576011
102 Link Spring 9306610012 9306610012
108 Base 9306566012 9306566012
109 Casing 9306569013 9306569013
127 Drain Hose Assy 9305550029 9305550029
133 Evaporator Cover 9306606015 9306606015
146 Evaporator Assy 9308200013 9308200013
158 Connecting Pipe Assy 9309515017 9308100016
169 Cross-flow Fan Assy 9307836015 9307836015
178 Motor Cushion-A (Fan Motor) 9303528006 9303528006
184-1 Thermistor Spring-A 313728262708 313728262708
189 Shaft Holder-C 9306628017 9306628017
217 Capacitor Holder 9309047013 9309047013
236 Controller PCB Assy 9703433054 9703433061
EZ-09903HSE-F
240 Remote Control Unit AR-FB5 9307979118 9307979118
268 Motor Cover-B 9306582012 9306582012
273 Lamp Cover Holder 9309048010 9309048010
281 Clamp Metal (Pipe) 9306607012 9306607012
323 Louver-B 9306584016 9306584016
385 Indicator PCB Assy 9704600011 9704600011
EZ-09903HSE-D(F)
401 Wall Hook Bracket 9306588014 9306588014
440 Flow Control Panel-U 9306570019 9306570019
557 Diffuser Spring 9306611019 9306611019
652-1 Therm. Holder Pipe 313714262805 313714262805
759 Intake Grille 9307130052 9307130052
764 Drain Cap Assy 9304150008 9304150008
767-1 Bottom Cover-A 9306567019 9306567019
777 Intake Grille Clamp 9306755010 9306755010
796 Control Box-D 9309049017 9309049017
815 Terminal-5P 9703455025 9703455025
873 Lamp Cover 9306593025 9306593025
875 Power Supply PCB Assy 9703434020 9703434020
EZ-09903HSE-P
876-1 Step Motor 9305780006 9305780006
876-2 Step Motor 9305892006 9305892006
960 Diffuser 9306572013 9306572013
962-1 Guard Holder-L 9307229015 9307229015
962-2 Guard Holder-R 9307228018 9307228018
963 Fan Guard Metal Rod 9305751020 9305751020
B Screw (w/Spring Washer) 0700179013 0700179013
C Control Box Assy 9309044012 9309044012
D Control Box Cover A 9309039018 9309039018
E Control Box Cover B 9309040014 9309040014
F Control Box Cover C 9309041011 9309041011
G Control Box Cover D 9309042018 9309042018
H Conduit Holder 9309043015 9309043015
Ref.
No.
Description
Ord.
Q’ty
Part No.
Ref.
No.
Description
Ord.
Q’ty
Part No.
ASU12R1AASU9R1A ASU12R1AASU9R1A
2 Fan Cover (Guard) 9304109006 9304109006
4 Emblem-Rear “FUJITSU” 9351355005 9351355005
5 Cabinet, Painted 9302936017 9302936017
7 Panel (Top) 9309013018 9309013018
9 Cabinet Rear Panel 9302935010 9303744017
12 Base Assy, Painted 9309476011 9309476035
13 3-Way Valve 9358715017 9358715017
14 2-Way Valve 9358714010 9358714010
16 Condenser Assy 9309659001 9309660007
32-2 Control Box Metal-A 9309057012 9309057012
34 Capacitor (Fan Motor) 9700468172 9700468172
38 Capacitor Clamp 313468061808 313468061808
39 Propeller Fan 9351589011 9351589011
41 Fan Motor Assy-Out 9600649053 9600649053
42 Bracket (Motor) 313166243804 313166243804
46 Compressor Assy 9309455016 9309456013
51 Special Nut M5 313199233602 ––––
51 Special Nut M6 –––– 313106278400
55 Special Nut M6 (For Comp.) 9307615016 9307615016
64 Running Capacitor 9306512064 9306512071
98 Fan Ring 313166296109 313166296109
107 Rubber Seat-A 9351813017 9351813017
109 Terminal Cover 9302419008 9351120009
138 Separate Wall Metal 9300672016 9303729014
198 Noise Insulation-A 9309688018 9309411012
213 Noise Insulation-B 9309689015 9309678019
343 Solenoid Coil 9357143002 9357143002
344 4-Way Valve 313947302811 313947302811
373 Grip 313166178700 313166178700
412 Terminal Gasket 9351505011 9351121006
413 Overload Relay 9351801014 313658062101
419 Posistor (For Comp.) 9351802011 ––––
420 Capillary Assy 9309641006 9309642003
519-2 Check Valve 9306824006 9306824006
527 Protective Net (Protection Cover) 313028228455 313028228455
734 Cabinet Top Plate 9302937014 9302937014
744 Condenser Mounting Bracket –––– 313166374106
745 Motor Support 313166036308 313166036308
815 Terminal-7P 9703455049 9703455049
823 Fuse Holder F-130 0500802111 0500802111
824 Fuse ST4 3A-250V 0600106546 0600106546
899 Bracket (Condenser) 9350768011 ––––
940 Hole Plug No.0875 9355891004 9355891004
941 Conduit Plate 9309203013 9309203013
A Screw (w/Washer) 9357297002 9357297002
Ref.
No.
Description
Ord.
Q’ty
Part No.
Ref.
No.
Description
Ord.
Q’ty
Part No.
AOU12R1AOU9R1 AOU12R1AOU9R1
