2013.10.29 2
OUTDOOR UNIT
AOU9RLFW1 AOU12RLFW1
26 inch (660 mm)
17-3/4 inch (454 mm)
21-1/4 inch (540 mm)
11-7/16 (290)
21-1/4 inch (540 mm)
11-7/16 (290)
31-1/8 in. (790 mm)
21-1/4 inch (540 mm)
DIMENSIONS
10-9/16 inch
(268 mm)
5/8 to 11/16
(15.8 to 16.7)
8 inch
(203 mm)
33-1/16 inch (840 mm)
INDOOR UNIT
Drain hose
Diameter
Outside
Inside : 9/16 inch
(13.8 mm)
23-5/8 inch (600 mm)
