Fujitsu AOU12RLFW1 Service Manual

Fujitsu AOU12RLFW1
26 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #9 background imageLoading...
Page #9 background image
1
2
3
4
5
6
7
2
1
3
VCC
OUT
GND
I C201
GP1UM261R
JM1
C203
0.1
<B>
+
C202
47/
10V
R202
47
<1/4W>
5V
A
A
A
SW201
KSHC611BT
5V
CN201
S7B-PH-K-S
D201 SL I-343 GREEN
D202 SL I-343 ORANGE
D203 SL I-343 GREEN
5V
2013.10.23 8
INDOOR UNIT
INDICATOR PCB
K12JZ-1200HSE-D0
