Fujitsu AOU15RLS2 Service Manual

OUTDOOR UNIT
2012.01.05 21
12 Compressor Assy 9318334005
15 3-way Valve Sub Assy 9317109062
18 Pulse Motor Valve Assy 9315587022
17 Solenoid 9970110023
11 Condenser Total Assy 9317089128
19 Expansion Valve Coil 9970095030
16 4-way Valve Assy 9318457018
14 2-way Valve Assy 9317171014
13 Valve Bracket 9331649001
Ref. Description Part number
13
17
16
18
19
15
14
12
11
