OUTDOOR UNIT
2012.01.13 22
-- Outdoor Thermistor 9900544041
25 ACTPM 9707592016
28 Terminal 6P 9900016081
26 Heatsink 9318614015
27 Choke Coil 9900223014
Capacitor PCB 9708514017
23
Main PCB
9709217023
24
-- Thermistor Assy 9900648008
21
Filter PCB
9708511276
22 Transistor PCB 9708646077
Ref. Description Part number
27
24
28
23
26
21
22
25
