Fujitsu AOU15RLS2 Design & Technical Manual

- (02 - 01) -
OUTDOOR UNIT AOU9-15RLS2 OUTDOOR UNIT AOU9-15RLS2
SPECIFICATIONS1.
Type INVERTER HEAT PUMP
Model name AOU9RLS2 AOU12RLS2 AOU15RLS2
Power sourse 208 / 230V
~
60Hz
Available voltage range 187 - 253V
~
60Hz
Starting current A 3.7 5.5 6.1
Fan
Airow
rate
Cooling
CFM
(m
3
/h)
1082 (1840) 1206 (2050)
Heating 1082 (1840)
Type × Q'ty Propeller fan × 1
Motor output W 115
Sound pressure level
Cooling
dB (A)
48 49 51
Heating 49 50 51
Heat exchanger type
Dimensions
(H × W × D)
in. 23-5/32 × 34-11/16 × 1-7/16
mm 588 × 881 × 36.4
Fin pitch FPI 20
Rows × Stages 2 × 28
Pipe type Copper
Fin Type Aluminum
Compressor
Type × Q'ty Rotary × 1
Motor output W 850 1000
Refrigerant
Type R410A
Charge
lbs.oz. 2lbs.10oz. 2lbs.12oz.
kg 1.20 1.25
Refrigerant oil Type FREOL α68SZ
Enclosure
Material Steel
Color
Beige
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
in. 24 - 1/2 × 31 - 3/32 × 11 - 11/32
mm 620 × 790 × 290
Gross
in. 28 - 1/16 × 37-7/32 × 15 - 9/16
mm 713 × 945 × 395
Weight
Net
lbs.(kg)
84 (38) 86 (39)
Gross 93 (42) 95 (43)
Connenction pipe
Size
Liquid
in. (mm)
Ø 1/4 (Ø 6.35)
Gas Ø 3/8 (Ø 9.52) Ø 1/2 (Ø 12.7)
Method Flare
Pre - charge length
ft. (m)
49 (15)
Max. length 66 (20)
Max. height difference 49 (15)
Operation range
Cooling
°F (°C)
14 to 115 (-10 to 46)
Heating -5 to 75 (-21to 24)
Note :
Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F (26.67°C) DB / 67°F (19.44°C) WB, and outdoor temperature of 95°F (35°C) DB / 75°F (23.9°C) WB.
Heating : Indoor temperature of 70°F (21.11°C) DB / 59°F (15°C) WB, and outdoor temperature of 47°F (8.33°C) DB / 43°F (6.11°C) WB.
Pipe length : 24ft.7in (7.5m), Height difference:0 m. (Outdoor unit - Indoor unit)
The protective function might work when using it outside the operation range.
