Fujitsu AOU36RLXFZ Service Manual

Total pipe length
ADDITIONAL CHARGE
MODEL NAME
POWER SUPPLY
FREQUENCY
NOISE LEVEL
AIR
CIRCULATION
ELECTRICAL DATA
MEASUREMENT
REFRIGERANT CHARGE
(When 2 indoor units are connected)
FAN MOTOR
208 V / 230 V
Cooling
Heating
Cooling
Heating
Cooling
Heating
TYPE 4 room multi inverter
AOU36RLXFZ
53 dB
55 dB
60 Hz
2,119 cfm (3,600 m
3
/h)
2,237 cfm (3,800 m
3
/h)
MAXIMUM PIPE LENGTH (each unit)
MAXIMUM PIPE LENGTH (total)
66 ft (20 m)
98 ft (30 m)
131 ft (40 m)
MINIMUM PIPE LENGTH (total)
ADDITIONAL CHARGE
(None)
8-13/16 oz (250 g)
1 lb 1-5/8 oz (500 g)
9/32 oz/ft (25 g/m)
49 ft (15 m)
82 ft (25 m)
MINIMUM PIPE LENGTH (each unit) 25 ft (7.5 m)
131 ft (40 m)
MAX ELEVATION (between indoor units) 33 ft (10 m)
MAX ELEVATION (between indoor and outdoor units) 49 ft (15 m)
Total pipe length
ADDITIONAL CHARGE
REFRIGERANT CHARGE
(When 3 or 4 indoor units are connected)
MAXIMUM PIPE LENGTH (each unit)
MAXIMUM PIPE LENGTH (total)
164 ft (50 m)
197 ft (60 m)
230 ft (70 m)
MINIMUM PIPE LENGTH (total)
ADDITIONAL CHARGE
(None)
8-13/16 oz (250 g)
1 lb 1-5/8 oz (500 g)
9/32 oz/ft (25 g/m)
66 ft (20 m)
82 ft (25 m)
MINIMUM PIPE LENGTH (each unit) 16 ft (5 m)
230 ft (70 m)
MAX ELEVATION (between indoor units) 33 ft (10 m)
MAX ELEVATION (between indoor and outdoor units)
49 ft (15 m)
COMPRESSOR
TYPE
DISCRIMINATION
TNB220FPBMT
WEIGHT
31 lbs 8-1/2 oz (14.3 kg)
PRECHARGED REFRIGERANT
REFRIGERANT TYPE R410A
7 lbs 4-7/16 oz (3,300 g)
Hermetic type, Inverter,
4 poles, 3 phase,
DC motor, Twin Rotary
32-11/16 x 35-7/16 x 13 inch
(830 x 900 x 330 mm)
149 lbs / 165 lbs
(68 kg / 75 kg)
OUTDOOR UNIT
SPECIFICATIONS
WEIGHT
DIMENSIONS
MFE-45VVT
850 r.p.m.
900 r.p.m.
H x W x D
Net / Shipping
HIGH SPEED
DISCRIMINATION
